Parts

Model 223177, Series D

UHMWPE and Leather Packed

Ref	Part
No.	No.	Description	Qty
1	180949	PACKING NUT/WET-CUP	1
3n	106555	O-RING; fluoroelastomer	2
4n	108832	O-RING; fluoroelastomer	2
5*	166489	V-PACKING; leather	2
6*	185662	GLAND, male	1
7*	171168	GASKET; nylon	1
8	185650	ROD, displacement	1
9	24C503	CYLINDER, pump	1
10	161743	CAP, rod, lower	1
11*	185630	PACKING, cup; UHMWPE	2
12n	160019	WASHER, back-up	1
13	180944	SEAT, piston valve	1
14	180930	HOUSING, intake valve	1
15n	101178	BALL, intake; steel;
		1–1/4” (31.8 mm) diameter	1
16	205061	RETAINER and SEAT, intake valve	1
17*	171177	GASKET; nylon	1
18	160006	PIN, straight	1
19	101529	SCREW, hex hd;
		3/8–16 x 2–3/4” (70 mm) long;
		w/nylon locking patch	3
20	171163	WASHER, flat	3
21n	185964	WASHER, piston	2

Ref	Part
No.	No.	Description	Qty
22n	100279	BALL, piston; steel;
		7/8” (22 mm) diameter	1
23	185651	ROD, plunger, adjustable	1
24	180932	HOUSING, outlet, pump	1
25*	185647	V-PACKING; UHMWPE	3
26*	185648	GLAND, female	1
27	190067	CAP, rod, upper	1
29	190176	UNION, adapter, straight;
		1” npt(m) x 1” npsm(f) swivel	1
30	110349	BOLT, hex hd; 3/8–16 unc–2a x
		9” (229 mm) long	4
31	100133	LOCKWASHER; 3/8” (10 mm) size	4
39*	185917	GASKET, piston; cellulose fiber	2
40Y	172479	TAG, warning (not shown)	1
42	160016	SPACER, piston	3
44Y	179761	TAG, warning (not shown)	1

*These parts are included in Repair Kit 223320, which may be purchased separately.

nKeep these spare parts on hand to reduce down time.

YReplacement Danger and Warning labels, tags and cards are available at no cost.

			42
	1		22n
			21n
	*26	27	39*
		4n	11*
	*25	5*	12n
29		8	13
		6*
		3n	11*
			39*
	24	23	21n
	*7		20
		n3	19
			15n
		n4
			16
	9	18
		10
		14
	*17		31
			30

06076

307983 9
