Cowon Systems U5 Am still confused even after reading the manual, Cannot turn on the player

Page 20

38Troubleshooting

QI am still confused even after reading the manual.

&

Our website www.COWON.com provides support for users of iAUDIO products with FAQ (Frequently Asked Questions) and

A



beginner’s guide for our products. Users are strongly encouraged to check out our website for further information regarding



product usages and software upgrades and patches.



For individual inquiries, please contact us on-line as we will try to help you best we can.

QI cannot turn on the player.

&Charge the battery fully in case the battery charge has been drained. If the battery is weak it may take a few seconds to power A on. If the player does not respond at all, first disconnect all USB and power cables, and then press the RESET button located at

the bottom of the player. RESET button simply powers off the player and does not affect the player in any other way.

QButtons won’t work.

&

Check to see if Power Switch is on HOLD position.

A

QThe player is on but there is no sound.

&

Check if the volume is set to 0

A



Check if the player has any music file stored in its disk. Damaged music files may not play or play improperly. Check the con-



nection of the earphones to the iAUDIO. Loose or blocked connection can cause inadequate contact between earphone jack



and the iAUDIO.

QVideo won’t play.

&

iAUDIO U5 does not support video

A

Q

FM Radio does not work.

&

iAUDIO does not have a separate antenna. Instead it uses earphone wire to receive FM Radio signals. Stretching the wires

A may enhance the reception quality.FM reception quality may vary by location. If reception issue continues after multiple tries from different locations, please contact our online customer support (http://www.COWON.com).

iAUDIO U5





Troubleshooting

39

Q

There is too much noise in my recordings.



&

iAUDIO U5 uses ultra-small embedded microphone, so it may be more susceptible to noise during recordings.



A







Q

Characters on the display are corrupted.



&



A

Reset the language using Settings-Display-Language menu and set display format to File name using Settings-Display-





Title menu.





If the problem continues, reset the player to its Factory Default setting. Some special fonts may not display perfectly.



Q

Computer cannot recognize the player when connected.



&

When connecting to the PC with a USB cable, please turn the player on before connecting USB cable. If it is still not



A

recognized by the PC, press RESET button next to the USB jack on the bottom of the player.



Connection to an external USB Hub may not be stable due to its low power. iAUDIO should be connected directly to a PC’s USB port.

iAUDIO may require additional driver installation for Windows 98 users. See section 1.7

QPlayer is not recognized by COWON MediaCenter - JetAudio and “No iAUDIO found” message appears.

& Check to see if the player is recognized in Windows Explorer when it is properly connected to PC. iAUDIO must be A recognized in the Windows for it to work with COWON MediaCenter - JetAudio.

Additional driver installation is required for Windows 98 and 98 SE users. See section 1.7.



Within COWON MediaCenter - JetAudio, set Settings-Device to match your iAUDIO model.

Q

Memory capacity of the player is different or smaller than specified.

&

The memory capacity indicated by Windows Explorer may be different from that indicated by the memory manufacturer.

A

iAUDIO uses some area in the drive for system operation. Therefore, the actual available capacity is somewhat reduced



after excluding system area.

Q

iAUDIO does not play properly when memory is full.

&

For iAUDIO to function properly, it requires at least 5 MB of space for saving settings and other system files.

A









iAUDIO U5

Page 19 Page 21
Image 20
Page 19 Page 21
Contents User Guide Legal Notice On-line registration and supportTable of Contents IAUDIO U5 at a Glance Safety TipsIntroducing iAUDIO U5 Package contents Features and specification Introducing iAUDIO U5Identifying the Parts TFT LCD Display BackCharging iAUDIO U5 Using an AC adapter sold separatelyUsing a PC connection Windows 98 Driver Setup Installing the driverConnecting to PC and Transferring Files Continue to click NextBasic Controls Using iAUDIO U5Quick Start Guide Playing Audio Using Advanced FeaturesPlaying Audio Files Using FM Radio Setting and Using Preset ChannelsFM Radio tuning mode, pressing Listening to FM RadioRecording Using Built-In Microphone Scheduled Recording of FM RadioRecording with Built-in Microphone During recording, pressUsing Advanced Settings Settings Menu ListMenu Screen JetEffectPlay Mode DisplayThis function does not operate during playback TimerGeneral Recording FM RadioSystem InformationAdditional Information Firmware UpgradeResetting the Player to Factory Default Settings Computer cannot recognize the player when connected IAUDIO does not play properly when memory is fullAm still confused even after reading the manual Cannot turn on the player

U5 specifications

The Cowon Systems U5 is a portable multimedia player that has gained attention for its combination of functionality, design, and audio quality. Released by Cowon, a company renowned for its innovation in portable media technology, the U5 aims to provide users with a versatile device for entertainment on the go.

One of the standout features of the Cowon U5 is its impressive audio support. The device is equipped with Cowon's renowned JetEffect sound enhancement technology, which includes various equalizer settings and sound effects. This allows users to customize their audio experience to suit their preferences, ensuring rich and clear sound playback across a wide range of audio formats.

The U5 supports numerous file formats, including MP3, WMA, OGG, APE, and FLAC, catering to audiophiles who appreciate high-quality music. The inclusion of features such as SRS WOW HD provides an immersive listening experience, enhancing audio depth and spatial quality, making the U5 an ideal choice for music lovers.

In addition to its audio capabilities, the Cowon U5 also supports video playback, enabling users to watch their favorite movies and shows on the go. The device features a vibrant display that enhances video content with bright colors and sharp details, delivering an enjoyable viewing experience. The U5 supports various video formats, adding to its versatility as a multimedia player.

Another important characteristic of the Cowon U5 is its user-friendly interface. The device is designed with intuitive navigation, making it easy for users to access their music, videos, and settings without hassle. The touchscreen interface further enhances usability, allowing for smooth scrolling and selection.

Durability and battery life are also key features of the U5. The device is built to withstand daily use while offering a lengthy battery life, providing hours of playback on a single charge. This makes it a practical companion for travel or extended use without the need for frequent recharging.

In summary, the Cowon Systems U5 encapsulates a blend of high-quality audio and video playback with a user-friendly design and robust features. Its diverse compatibility with various media formats, along with innovative sound technologies, makes it an appealing choice for anyone seeking a reliable and versatile multimedia player in the digital age.
