A CLOSER LOOK
what’s included
Weld-Pak® 140HD (K2514-1) Includes:
Gun
•Magnum® 100L gun and 10 ft. (3.0 m) cable assembly with brass gun connection and
•.025” (0.6 mm) Contact Tips (Qty. 3) (KH710)
•.035” (0.9 mm) Contact Tips (Qty. 3) (KH712)
•Gasless Nozzle for Innershield® welding (KH726)
•Gas Nozzle for MIG welding (KH725)
Drive
•Spindle Adapter for 8” (203 mm) Diameter Spools (KH720)
•.025” (0.6 mm) Wire Diameter Drive Roll for MIG welding
•.035” (0.9 mm) Wire Diameter Drive Roll for MIG welding
•
Cored welding
Shielding Gas Apparatus
•Harris® 3000290 Gas Regulator (S25805) and 52 in. (1.3 m)
Hose (S19303) for use with CO2 or argon blend gases. (For use with CO2 shielding gas, order a Lincoln® S19298 CO2 shielding gas bottle adapter.)
Welding Wire
•2 lb. (0.90 kg) Spool of .025” (0.6 mm) diameter SuperArc®
•1 lb. (0.45 kg) Spool of .035” (0.9 mm) diameter Innershield®
Other
•Work Clamp and 10 ft. (3.0 m) Cable
•Handshield (G3364)
•Instruction Manual
•How to Use DVD (S26375)
•Learn to Weld Manual (LTW1)
performance plus
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| drive rolls |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Product | Wire Diameter | Type/ |
|
|
|
|
|
|
|
|
|
|
|
|
|
| ||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Number | in (mm) | Process |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||
|
|
|
| 1 |
|
|
|
|
|
|
|
| .025 (0.6) | Smooth/MIG | |||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| .035 (0.9) | Smooth/MIG | |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SP- Single Pass.
MP- Multiple Pass.
1Aluminum welding requires optional
recommended options
General options
Welding Cart
Order K2275-1
Utility Cart
Heavy duty cart stores and transports welder, 150 cubic foot shielding gas cylinder, welding cables and accessories. Includes stable platforms for welder and gas bottle platform, lower tray for added storage capacity and adjustable height handle.
Order K520
| |
