6. Set up

CUTTERCASE

WARNING

The blade has very sharp edges. Be sure to use pro- tective gloves whenever handling it.

1.Remove the fastening screw(long) and the lock screw(short) from the cuttercase.

2.While aligning the locking holes, install the cuttercase assembly to the shaft casing.

3.Align the locking holes and screw in the lock screw to the bottom by hand, then secure it with the wrench provided. Do not tighten up the lock screw with the holes out of alignment, or the cuttercase can be dam- aged.

Locking holes

Cuttercase

NOTE

If the locking screw is tightened up with the holes out of alignment, the cuttercase may be damaged.

4. Fasten the cuttercase fastening screw.

BLADE GUARD

Install the blade guard onto the shaft casing approx. 3cm away from the cuttercase. Fasten the clamp uniformly.

SGCZ2600DL/SGCZ2600DW

G

B

GB-9
