DeWalt DWD210G manual Descripción, USO Previsto

Page 6

La etiqueta de la herramienta puede incluir los siguientes símbolos. A continuación se indican los símbolos y sus definiciones:

V

voltios

A

amperios

Hz

hertz

W

vatios

min

minutos





............corriente alterna







.....corriente directa





corriente alterna o

















Construcción Clase I

no

directa











..........







(con conexión a tierra)

velocidad sin carga

FIG. 1

D

DWD210G

B



Construcción Clase II







terminal a tierra









..........





.............



(con aislamiento doble)





.............

símbolo de alerta

RPM

revoluciones o







de seguridad



reciprocidad

…/min

por minuto



por minuto

gpm/ipm...

golpes por minuto

DESCRIPCIÓN (FIG. 1, 2)

ADVERTENCIA: Nunca modifique la herramienta eléctrica ni ninguna pieza de esta. Puede producir daños o lesiones corporales.

A. Gatillo conmutador

B. Palanca de reversa

C. Mango lateral

D. Mandril

USO PREVISTO

NO utilice la herramienta en condiciones húmedas o en la presencia de líquidos o gases inflamables.

Estos taladros industriales son herramientas eléctricas profesionales. NO permita que un niño juegue con ellos. Si el operador no tiene experiencia operando esta herramienta, su uso deberá ser supervisado.

C A

E

F

C

5

Image 6 DeWalt DWD210G manual Descripción, USO Previsto
