QuickSpecs

HP rp5800 Retail System

Technical Specifications

Power Supply

240-watt – EPA90 power supply – Active PFC



*This power supply meets ENERGY STAR compliance in conjunction



with a select range of processors and modules.

Operating Voltage Range

90 to 264 VAC

Rated Voltage Range

100 to 240VAC

Rated Line Frequency

50/60 Hz

Operating Line Frequency Range

47 – 63 Hz

Rated Input Current

4A



Efficiency 87/90/87% at 20/50/100% load

Power Supply Fan

80 mm variable speed fan

ENERGY STAR Compliant

ENERGY STAR 5.0 compliant

Power Cord Length

6.0ft (1.8 3m)

Current Leakage (NFPA99)

< 275 µA

ROM BIOS Information

Key features of the HP BIOS include:

Deployment and manageability – HP BIOS provides several technologies that help integrate the HP rp5800 Retail System into retail, such as PXE, remote configuration, remote control, and F10 Setup support for 12 languages.

Select models feature either Intel Standard Manageability or vPro Technology.

Stability – HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced change notification.

Computrace agent – For tracking and tracing services, available in select countries, separate software and purchase of a subscription is required.

Thermal and power management – The HP BIOS provides and enables thermal and power management technologies so component temperatures are managed for high reliability and to assist in operating the HP rp5800 Retail System in any retail environment.

Acoustic performance – Industry leading acoustic emissions across the range of operating conditions. Serviceability – HP BIOS provides diagnostic and detailed service information.

Upgrades and recovery – HP BIOS provides numerous ways to upgrade HP the HP rp5800 Retail Systems, including BIOS updates from within DOS (Flashbin), BIOS updates from within Windows (HPQFlash), HP Client Manager, and fail-safe recovery. In addition, the HP rp5800 Retail System BIOS Utilities tool enables replicated BIOS setup throughout the Enterprise; it is available from within the BIOS software and from the support website

Additional HP BIOS Features

Power-On password – Helps prevent an unauthorized user from powering on the system.

Administrator password – Also known as the setup password, this helps prevent unauthorized changes to the system configuration. If the administrator password is not known, the BIOS version cannot be changed and changes cannot be made to BIOS settings using F10 setup or under the OS.

Advanced Configuration and Power Interface (ACPI) – Represents a significant innovation in power and configuration management, allowing operating systems and applications to manage power based on activity and usage. HP rp5800 Retail Systems use ACPI to provide power conservation features.

S5 Max Power Savings setting supports EU Lot6 requirement and allows the HP rp5800 Retail System to power down below 1W is S5 (when turned off). When S5 Max Power Savings feature is enabled power to slots is turned off along with WOL functionality.

DA - 13982 North America — Version 12 — November 8, 2013

Page 18

Image 18
