QuickSpecs
HP StorageWorks RDX Removable Disk Backup System
Technical Specifications
| Compressed | 320 GB | 640 GB | 1 TB | Choice of 320 GB, |
| (assumes 2:1 |
|
|
| 640 GB or 1 TB |
| application based |
|
|
|
|
| data compression) |
|
|
|
|
Performance | Average sustained | 30 MBs | 30 MBs | 30 MBs | 30 MBs |
| transfer rate, native |
|
|
|
|
| Average sustained | 60 MBs | 60 MBs | 60 MBs | 60 MBs |
| transfer rate, |
|
|
|
|
| compressed |
|
|
|
|
| (assumes 2:1 |
|
|
|
|
| application based |
|
|
|
|
| data compression) |
|
|
|
|
| Burst transfer | 480 MBs | 480 MBs | 480 MBs | 480 MBs |
| rate(USB) |
|
|
|
|
| Data access time | 15 milliseconds | 15 milliseconds | 15 milliseconds | 15 milliseconds |
| Supported file | FAT32, NTFS, ext2, | FAT32, NTFS, ext2, | FAT32, NTFS, ext2, | FAT32, NTFS, ext2, |
| systems | ext3 | ext3 | ext3 | ext3 |
Reliability | MTBF (Dock) | 550,000 hours | 550,000 hours | 550,000 hours | 550,000 hours |
|
| @100% duty cycle | @100% duty cycle | @100% duty cycle | @100% duty cycle |
| MTBF (cartridge) | 500,000 hours | 500,000 hours | 500,000 hours | 500,000 hours |
| Uncorrected Error | 1 error per 1014 | 1 error per 1014 | 1 error per 1014 | 1 error per 1014 |
| Rate | bits read | bits read | bits read | bits read |
Media | Docking Station | 10,000 (minimum) | 10,000 (minimum) | 10,000 (minimum) | 10,000 (minimum) |
| Load/Unload cycles |
|
|
|
|
| Cartridge | 5,000 (minimum) | 5,000 (minimum) | 5,000 (minimum) | 5,000 (minimum) |
| Load/Unload cycles |
|
|
|
|
Compatibility |
| Backwards and | Backwards and | Backwards and | Backwards and |
|
| forwards | forwards | forwards | forwards |
|
| compatibility to any | compatibility to any | compatibility to any | compatibility to any |
|
| current/future RDX | current/future RDX | current/future RDX | current/future RDX |
|
| removable disk | removable disk | removable disk | removable disk |
|
| cartridge | cartridge | cartridge | cartridge |
Interface | Interface type | USB 2.0 | USB 2.0 | USB 2.0 | USB 2.0 |
| USB connector | USB standard series | USB standard series | USB standard series | USB standard series |
|
| B receptacle | B receptacle | B receptacle | B receptacle |
Power Specifications | Power | +5V ± 5% (100mV | +5V ± 5% (100mV | +5V ± 5% (100 | +5V ± 5% (100 |
| requirements, | Max ripple) @1.3A | Max ripple) @1.1A | mV Max ripple) @ | mV Max ripple) @ |
| Internal | +12V ± 10% | +12V ± 10% | 1.1 A | 1.1 A |
|
| (150mV Max ripple) | (150mV Max ripple) | +12V ± 10% (150 | +12V ± 10% (150 |
|
| @0.005A | @0.4A | mV Max ripple) @ | mV Max ripple) @ |
|
|
|
| 0.4 A | 0.4 A |
| Power | 100 to 240 VAC, | 100 to 240 VAC, | 100 to 240 VAC, | 100 to 240 VAC, |
| requirements, | ||||
| External | ranging | ranging | ranging | ranging |
| Power consumption 6.6W/20 W | 6.6W/20 W | 6.6W/20 W | 6.6W/20 W | |
|
| (typical/peak) | (typical)/ (peak) | (typical)/ (peak) | (typical)/ (peak) |
Environmental | Temperature range | 5 to 45º C; 41 to 113º F (operating)- |
|
|
DA - 13036 EMEA — Version 5 — June 5, 2009 | Page 13 |
