3 Operating the touch screen

Installing the touch software

Microsoft Windows 7/Vista/XP (plug and play)

NOTE: Refer to Connecting the cables on page 5 for instructions on connecting the USB cable.

When you connect the USB cable between the monitor and a computer running Windows 7, Windows Vista, or Windows XP, the touch driver software will automatically install. The driver software may take a minute to install, and for Windows 7 and Windows Vista a message will display on the monitor screen indicating that the driver software has been installed successfully. After the touch driver software is installed, you can select, launch, and drag objects using the touch screen. To make a selection, touch the screen.

NOTE: For Windows XP, the touch driver loads as an input device, so there will be no message verifying the driver installation.

NOTE: Multi-touch gestures are supported in Windows 7 Home Premium, Professional, Enterprise, and Ultimate operating system editions only. Multi-touch is not supported in Windows 7 Home Basic or Starter editions, Windows Vista, or Windows XP.

NOTE: If touch control does not begin to work within 20 seconds, you should verify that the touch driver is installed.

To verify that the touch driver is installed:

Windows 7—SelectStart > Control Panel > System and Security > System, and ensure that Pen and Touch: Touch Input Available with 2 Touch Points is listed in the System section.

Windows Vista—SelectStart > Control Panel > Mobile PC > Pen and Input Devices. If the Touch tab appears, touch input is available.

Installing the touch software

15

Image 21
Contents HP Compaq L2206tm and L2206tmp LED Backlit Touch Monitors First Edition April Document Part Number About this guide Iv About this guide Table of contents Page HP LCD Touch Monitors Product featuresPage Unfolding the monitor pedestal base Setting up the monitorComponent Description Rear componentsConnecting the cables 5Installing the cable management clip Setting up the monitor 7Adjusting the height Adjusting the monitor Adjusting the monitor8Pivoting the monitor Setting up the monitor Front components Front componentsTurning on the monitor 10Connecting USB devices Connecting USB devicesRemoving the monitor pedestal base 12Removing the pedestal base Setting up the monitorMounting the monitor Locating the rating labels Installing a cable lockInstalling the touch software Operating the touch screenMicrosoft Windows 7/Vista/XP plug and play Page Using the touch function Using an extended display Windows 7 only1Gesture compatiblity 3Select the display Operating the touch screen Page Tips Tips and troubleshooting2Touch screen troubleshooting Touch screen troubleshootingFinding more information Technical specifications Table A-1L2206tm/L2206tmp specificationsL2206tm/L2206tmp Appendix a Technical specifications Table A-2Factory preset modes Recognizing preset display resolutionsL2206tm/L2206tmp Table A-3High Definition video formatsEntering user modes Energy saver featureLCD monitor quality and pixel policy

L2206tm Touch specifications

The HP L2206tm Touch is a versatile and innovative touchscreen monitor designed for professional environments that require both functionality and user-friendly features. This monitor is particularly suitable for settings such as retail, hospitality, and business meetings, where interactive displays are essential for engagement and productivity.

One of the standout features of the HP L2206tm is its 21.5-inch display size, which boasts a full HD resolution of 1920 x 1080 pixels. This resolution ensures that visuals are sharp and clear, making it perfect for presentations, video playback, and detailed applications. The touchscreen technology utilized in this monitor is both responsive and intuitive, allowing users to interact with the screen using simple gestures like tapping, swiping, and scrolling. This touch capability enhances the user experience, making it easier to navigate through menus and applications without the need for a traditional mouse or keyboard.

The HP L2206tm Touch incorporates IPS panel technology, which provides wide viewing angles and accurate color reproduction. This means that users can view the screen from nearly any angle without experiencing significant color distortion or loss of clarity. The anti-glare coating on the display also contributes to its usability in various lighting conditions, reducing reflections and enhancing visibility.

Connectivity is another key aspect of the HP L2206tm. The monitor features multiple input options, including HDMI, VGA, and USB ports, which facilitate easy connection to a variety of devices such as computers, laptops, and multimedia players. The built-in USB hub further adds to its convenience, enabling users to connect peripherals such as keyboards, mice, and external storage devices directly to the monitor.

The design of the HP L2206tm is sleek and modern, with a matte black finish that complements any professional setting. Its adjustable stand allows for tilting and height adjustments to optimize ergonomic comfort, ensuring that users can find the perfect viewing position while working. Additionally, the monitor is environmentally friendly, compliant with Energy Star standards, and designed to reduce energy consumption.

In summary, the HP L2206tm Touch monitor combines high-definition visuals, responsive touchscreen technology, versatile connectivity options, and a user-friendly design. Its array of features makes it an excellent choice for businesses looking to enhance interactivity and engagement in their operations, making it a reliable tool for modern work environments.
