HOME CONTROL

The X10 button on the SentinelPro Camera’s remote control is your gateway to a world of useful control and automation solutions built by X10. Why enter a dark room when there is a simple

and affordable solution that can keep you safe and secure? From a simple remote control that can turn on a lamp, to a full-blown automation system, X10 provides you with all the products you need.

With the correct components in your X10 system, you can have all of these powerful options at your control:

·Enhance the color, brightness and detail of your camera’s subject by adding more light automatically

·Give your home a secure appearance by scheduling when lights and other electronics turn on and off

·Distribute audio and video to stereos and televisions using wireless technology

·Turn on house lights while sitting in your car

·Schedule sprinkler systems

·Control your lights and electronic devices using your personal computer

X10’s control and automation products are easy to install and extremely affordable. Visit X10.com today for more information and the latest products to build and enhance your X10 system.

Home Control

Controlling X10 Modules

Here’s how to control X10 modules with your SentinelPro Remote Control. The remote is set to House Code A by default.

1.Press and release the X10 button.

2.Use the number buttons to enter the Unit Code number of the chosen module. (You can press 1, then 6 for Unit Code 16).

3. Press the appro- priate button (labeled in blue) for the function you require (On, Off, Bright, Dim, All Lights On, All Units Off).

Note: when using buttons C1, C2, C3, and C4 to control cameras, they will also turn on X10 modules set to A1, A2, A3, and A4. To turn these modules off, use the procedure described above.
