Samsung UE55D7000LSXZF Présentation de la télécommande, Installation des piles type de pile AAA

Page 25

Présentation de la télécommande

Ceci est une télécommande spéciale destinée aux malvoyants. Elle dispose de points Braille sur les boutons Power, Channel et Volume.

Permet d’allumer et d’éteindre le téléviseur.

Permet d’afficher et de sélectionner les sources vidéo disponibles.

Donne un accès direct aux chaînes.

POWER ON/OFF

SOURCE

Active ou désactive l’éclairage de la télécommande. Lorsque l’éclairage est activé, les boutons enfoncés restent allumés pendant quelques instants. (Utiliser la télécommande avec ce bouton réglé sur ON réduit la durée de vie de

la pile.)

Choisissez Teletext Activé, Double, Mix ou ARRET.

Règle le volume.

TTX/MIX

MUTE

CH LIST

PRE-CH Permet de revenir à la chaîne

précédente.

Permet d’arrêter temporairement le son.

Permet de changer de chaîne.

Permet d’ouvrir l’affichage à l’écran.

Permet d’accéder à divers services d’applications.

Permet de sélectionner rapidement les fonctions fréquemment utilisées.

Permettent de sélectionner les éléments des menus à l’écran et de modifier les valeurs des menus.

Permet de revenir au menu précédent.

Ces boutons sont utilisés dans les menus Gestion chaînes, SMART HUB, etc.

Ces boutons ont des fonctions spécifiques. Pour plus d’informations, reportez-vous au manuel électronique.

Permet d’afficher les listes des chaînes

à l’écran.

Permet d’afficher le Guide électronique des programmes (EPG).

permet d’afficher des informations à l’écran.







Capteur OFN (Optical Finger Navigation)







Lorsque la fonction Navigation complète







est activée, il peut être utilisé comme







pointeur.







Si vous n’appuyez sur aucun bouton







pendant 30 secondes, le capteur est







éteint automatiquement. Pour réactiver le

TV





capteur, appuyez sur les boutons ENTER,





Navigation, Colour, REW, FF, Return.

SOCIAL





Pendant l’utilisation du capteur, le







rétroéclairage ne fonctionne pas.

E-MANUAL

P.SIZE

AD/SUBT.

Permet de quitter le menu.

SOCIAL TV: affiche l’écran Social TV. SEARCH: aide pour la recherche par mot pour les recommendations et la fonction de recherche.

W: définit la vidéo fournissant le signal 3D.

E-MANUAL : affiche le e-Manual.

P.SIZE : sélectionne le Format de l’image.

AD/SUBT. : permet d’activer ou de désactiver la description audio (non disponible pour tous les pays). / Permet d’afficher les sous-titres numériques.

Installation des piles (type de pile : AAA)

Français - 5
