Samsung EV1SRH/ELS Connecting to an External Source, Viewing the Various Functions on Your System

Page 9

Connecting to an External Source

The auxiliary input can be used to take advantage of the sound quality of your ULTRA SLIM audio system when listening to other sources.

Examples: A television

A video disc player

A Hi-Fi stereo video cassette recorder

To connect the external source, the source must have an audio output. In addition, you need an RCA connection cable.

1 Set the system to standby mode and disconnect it and the external source from the main.

2 Connect the audio cable to the rear of the ULTRA SLIM audio system.

Connect the...

To the connector marked...

Red jack

R (right)

White jack

L (left)

For optimum sound quality, do not invert the right and left channels.

3 Plug the system back into the main socket and press On/Standby

( ) to switch it on.

4 Select the AUX source by pressing the AUX button. Result: AUX is displayed.

5 Switch the external source on.

6 Adjust the volume and balance as required:

Volume Equalizer S.Bass

Example: You can watch a film and take advantage of stereo sound provided that the original sound track is in stereo (as if you were in a cinema).

AUX IN

LL

SPEAKERS

(6 )

RR

Timer Timer/

On/Off Clock

P.Sound Sleep AUX

S.Bass EQ Demo Dimmer

RDS

Viewing the Various Functions on Your System

GB

You can view the various functions available on your system.

1 Press the Demo button.

Result: The various functions available are listed in turn on the display.

All these functions are described in detail in this booklet. For instructions on how to use them, refer to the appropriate sections.

2 To cancel this function, press Demo again.

Timer Timer/

On/Off Clock

P.Sound Sleep AUX

S.Bass EQ Demo Dimmer

RDS

Open/Close +10 Display PTY

CD

Adjusting the brightness of the LCD display

You can adjust the brightness of the LCD display depending on the surrounding lighting conditions

Press the Dimmer button on the remote control to adjust the brightness.

The selection switches each time the button is pressed:

Dimmer1(Bright) ➞ Dimmer2 (Medium) ➞ Dimmer3(Dim).

Timer Timer/

On/Off Clock

P.Sound Sleep AUX

S.Bass EQ Demo Dimmer

RDS

Open/Close +10 Display PTY



CD



Program/

VOL.

Band

Set





8
