3-13 Product Operating Buttons

Product Operating Buttons

• Press one of the buttons on the monitor. OSD Guide will appear on the screen.

•If you press a button on the front of the monitor, an OSD Guide will display showing the function of the button before the menu for the pressed button appears.

•To go to the menu, press the button on the front of the monitor again.

•OSD Guide may vary according to functions and models. Please refer to actual product.

ICON

DESCRIPTION





Press this button to view the On Screen Display (OSD).

This button is also used to exit the OSD or to return to a higher-level OSD menu







* OSD Adjustment Lock











This function locks the OSD in order to maintain the current settings or to prevent the settings







from being changed by another person



MENU

On: If you press and hold the MENU button down for 10 seconds, the OSD Adjustment Lock







function is activated.











Off: If you press and hold the MENU button down for 10 seconds again, the OSD Adjustment







Lock function is disabled.













Even if the OSD Adjustment Lock function is activated, users can adjust the brightness









and contrast and can set up the adjustment function assigned to the [

].















Users can set the <Customized Key> to one of the following functions. If the user presses the







Customized Key [ ] after setting it, the configured function will be performed









• <

Angle> - <

Bright> - <Eco Saving> - <Image Size>











• You can set the function of the Customized Key by selecting <SETUP&RESET > ->

























<Customized Key> in the OSD.











• The function of the customized key can be changed by pressing the

button in the









customized key window.













▲/▼

Use these buttons to navigate the menu or to adjust a value in the OSD.



















Use this button to control the brightness of the screen.











Using the product
