Page 38

Starting play mode

Movie clip capture function : capture still images from the movie clip.

On camera movie trimming : You can extract desired frames of movie clip during the movie clip play back.

How to capture the movie clip

Steps 1-3 are the same as those for playing back a movie clip.

4.Press the Play / Pause button while playing the movie clip. Then press the E button.

5.The paused movie clip is saved in a new file name.

The captured movie clip file has same size as the original movie clip (640X480, 320X240, 160X128).

Play: /

Capture:E

[Paused]

[Pressing the E button]

If the running time is under 10 seconds, the movie clip can’t be trimmed.

1.Press the Pause button at the point of the movie clip that you want to start extracting.

2.Press the T button. (The start point doesn't display on the status bar, but the start point will be marked.)

3.Press the Play & Pause button and the extracted range will be displayed on the status bar.

4.Press the Play & Pause button once more at the point where you wish the extracted file to stop.

5.Press the T button and a confirmation window will display.

6.Select a desired sub menu by pressing the Left/ Right button and press the OK button.

[Yes]

: The extracted frames are saved as a new



file name.

[No]

: The movie trimming will cancel.

Play"

Capture:E

Trim:TCapture:E

Trimming?

Yes No

Confirm:OK

INFORMATION

If you want to extract the movie clip at the beginning of the frame, press the Zoom T button before starting the movie clip.

If the time line bar passes by the start point by pressing the REW (Left) button, the first frame of the movie clip will display.

If you don’t specify the ending point of the movie clip, the trimming confirmation window will display at the point of the last frame.

37
