Page 29

Network Setup

Select a Network

: Not Selected ►

Internet Protocol Setup

: Auto

IP Address

:

































Subnet Mask

:

































Gateway

:









































































DNS

: Auto

DNS Server

:





































PBC(WPS)

U Move E Enter R Return





7.Press the Red button on your remote.

8.Press the PBC (WPS) button on your router within 2 minutes. Your TV player automatically acquires all the network setting values it needs and connects to your network.

9.After the network connection is set up, press the RETURN button to exit the Network Setup screen.

Network Setup (Auto)

Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network. If you use this method of setting up the network connection, and have a Security Key for your wireless network, you will have to enter the Pass Phrase during the setup process.

How to set up automatically

To set up the wireless connection automatically, follow these steps:

1.Follow Steps 1 through 6 in the “How to set up using PBC (WPS)” (p. 28).

2.Press the ▼ button to select Internet Protocol Setup, and then press the ENTEREbutton. Press the

▲ or ▼ button to select Auto, and then press the ENTEREbutton.

3.Press the ▲ button to go to Select a Network, and then press the ENTEREbutton. The Network function searches for available wireless networks. When done, it displays a list of the available networks.

4.In the list of networks, press the ▲ or ▼ button to select a network, and then press the ENTEREbutton.

If the AP is set to Hidden (Invisible), you have to select Add Network and enter the correct Network Name (SSID) and Security Key to establish the connection.

5.If the Security/PIN pop-up appears, go to Step 6. If the Network Connecting Screen appears, go to Step 10.

6.Press the ▲ or ▼ button to select Security or PIN. For most home networks, you would select Security (for Security Key). The Security Screen appears.

Network Setup

Security Key

















0 entered

A

B

C

D

E

F

G



0~9 Number

H

I

J

K

L

M

N





Lower case





O

P

Q

R

S

T

U





Delete





V

W

X

Y

Z









Space



















nMove

E Enter R Return

7.On the Security screen, enter your network’s Pass

Phrase.

You should be able to find the Pass Phrase on one of the set up screens you used to set up your router or modem.

8.To enter the Pass Phrase, follow these general directions:

––Press the number buttons on your remote to enter numbers.

––Use the direction buttons on your remote to move from button to button on the Security Key screen.

––Press the Red button to change case or display symbols/characters.

––To a enter letter or symbol, move to the letter or symbol, and then press the ENTEREbutton.

––To delete the last letter or number you entered, press the Green button on your remote.

9.When done, press the Blue button on your remote. The Network Connecting screen appears.

10.Wait until the connection confirmation message is displayed, and then press the ENTEREbutton. The Network Setup screen re-appears.

11.To test the connection, press the RETURN button to select Network Test, and then press the ENTERE button.

04 Advanced Features

English 29

Image 29
