STEP 3

Adjusting the levelling feet

When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible.

1.Slide the washing machine into position.

2.Level your washing machine by turning the

leveling feet in and out as necessary by hand.

3.When your washing machine is level, tighten the nuts using the wrench supplied with your washing machine.

01 SETTING UP

STEP 4

Connecting the water and drain

Connecting the water supply hose

1.Take the L-shaped arm fitting for the cold water

supply hose and connect it to the cold water supply intake on the back of the machine. Tighten by hand.

The water supply hose must be connected to the washing machine at one end and to the water tap at the other. Do not stretch the water supply hose. If the hose is too short, replace the hose with a longer, high pressure hose.

2. Connect the other end of the cold water supply hose to your sink’s cold water tap and tighten it by hand. If necessary, you can reposition the water supply hose at the washing machine end by loosening the fitting, rotating the hose, and retightening the fitting.

For selected models with an additional hot water intake:

1.Take the red L-shaped arm fitting for the hot water supply hose and connect it to the hot water supply intake on the back of the machine. Tighten by hand.

2.Connect the other end of the hot water supply hose to your sink’s hot water tap and tighten it by hand.

3.Use a Y-piece if you only want to use cold water.

setting up your new washing machine _13
