Samsung YP-Z5FQS/XSG, YP-Z5FQB/HAO Touchpad works better when Pressed lightly with a fingertip

Page 12

Checking the Product and Accessories

Button Functions (Continued)

Buttons		Functions and Use

■Moving up, down, left and right and Function Selection

Tap on the top or bottom side to move up or down by one selection.

Tap on the left or right side to move left or right by one selection (Picture mode).

Tap and hold on top or bottom side to move up or down continuously.

Press the center of the Touchpad to select the function and move to the next screen.

✽ The touchpad works better when

pressed lightly with a fingertip.

		■ Do not use any sharp object other than your fingers to operate the touchpad. Otherwise, touchpad
CAUTION		may be damaged.
CAUTION

■Do not press on the [Touch Pad] if your fingers are not clean.

Image 12
