ECO Drum Clean

cleaning and maintaining your washing machine

Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life.

This course is a self-cleaning course that removes mold that may occur inside the washing machine.

1.Press the Power button.

2. Turn the Cycle Selector to the ECO Drum Clean course.

• You can only use the Delay End function.

• The water temperature during the ECO Drum Clean is set to 70 ˚C.

You cannot change the temperature.

3.Place the appropriate amount of cleansing agent into the

detergent compartment and close the detergent drawer (when cleaning the drum using a cleansing agent).

• Be sure to use the recommended cleansing agent for cleaning the drum.

• There are powder-type and liquid-type drum cleansing agents.

4.Press the Start/Pause button.

• If you press the Start/Pause button, the ECO Drum Clean course begins.

•Using the ECO Drum Clean course, you can clean the drum without using a cleansing agent. CAUTION • Never use the ECO Drum Clean course when laundry is in the washing machine. This may

result in damage to the texture or a problem with the washing machine.

•Use only 1/10 of the amount of the drum cleansing agent recommended by the cleansing agent manufacturer.

•Since using a chlorine bleaching agent may discolor the product, be sure to use only oxygen bleaching agents.

•Powder-type cleansing agent: Use a [powder-type bleaching agent] or a [cleansing agent for drum cleaning only].

•Liquid-type cleansing agent: Use a [liquid-type oxygen bleaching agent] or a [cleansing agent for drum cleaning only].

The ECO Drum Clean Auto Alarm Function

•If the “ECO Drum Clean” indicator on the display and the lamp on the Cycle Selector are lit after a wash, it indicates

that tub (drum) cleaning is required. In this case, remove the laundry from the washing machine, turn the power on, and clean the drum by performing the ECO Drum Clean course.

• If you do not perform the ECO Drum Clean course, the “ECO Drum Clean” indicator on the display and the lamp on the Cycle Selector are turned off. However, the “ECO Drum Clean” indicator on the display and the lamp on the Cycle Selector are turned on again after two washes are performed. However, this will not result in a problem with the washing machine.

•Although generally, the ECO Drum Clean Auto Alarm appears once a month or so, the frequency may differ depending on the number of times the washing machine is used.
