Hotpoint FZFM 151 xx Troubleshooting, Disposal, Respecting and conserving the environment

Page 7

Do not use any sharp or pointed utensils or electrical equipment - other than the type recommended by the manufacturer - inside the frozen food storage compartments.

Do not put ice cubes taken directly from the freezer into your mouth.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

Keep packaging material out of the reach of children! It can become a choking or suffocation hazard.

Disposal

Observe local environmental standards when disposing packaging material for recycling purposes.

The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance it must be separately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

Respecting and conserving the environment

Install the appliance in a fresh and well-ventilated room. Ensure that it is protected from direct sunlight and do not place it near heat sources.

Try to avoid keeping the door open for long periods or opening the door too frequently in order to conserve energy.

Do not fill the appliance with too much food: cold air must circulate freely for food to be preserved properly. If circulation is impeded, the compressor will work continuously.

Do not place hot food directly into the refrigerator. The internal temperature will increase and force the compressor to work harder and will consume more energy.

Defrost the appliance if ice forms (see Maintenance). A thick layer of ice makes cold transference to food products more difficult and results in increased energy consumption.

Regularly check the door seals and wipe clean to ensure they are free of debris and to prevent cold air from escaping (see Maintenance).

The ALARM indicator light

is flashing and the buzzer

sounds at regular intervals.



b)The temperature in the freezer has reached a dangerous level. The food must be disposed immediately.

a/b) In both these cases the freezer will maintain a certain temperature so that the food does not re-freeze. To restore normal operation bring the TEMPERATURE CONTROL knob setting to OFF and turn the appliance on again.

The buzzer sounds at regular intervals.

The appliance door has been left open for longer than 2 minutes. The buzzer will stop sounding when you shut the door.

The ALARM indicator light

remains illuminated

constantly.



The door has been opened too frequently.

The TEMPERATURE CONTROL knob is not in the correct position.

The motor runs continuously.

The SUPER FREEZE button has been pressed: the yellow FAST FREEZE indicator light is on (see Description).

The door is not closed properly or is continuously opened.

The outside ambient temperature is very high.

The appliance makes a lot of noise.

The appliance has not been installed on a level surface (see Installation).

The appliance has been installed between cabinets that vibrate and make noise.

The internal refrigerant makes a slight noise even when the compressor is off. This is not a defect, it is normal.

The green POWER indicator light is flashing.

The appliance is not operating correctly. Contact the Technical Assistance Centre.

GB

Troubleshooting

If the appliance does not work, before calling for Assistance (see

Assistance), check for a solution from the following list.

The green POWER indicator light does not illuminate.

The plug has not been inserted into the electrical socket, or not far enough to make contact, or there is no power in the house.

The motor does not start.

The appliance comes with a motor protection control (see Start-up and use).

The ALARM indicator light is illuminated and the buzzer sounds at regular intervals.

a)The temperature in the freezer is too high. Check the quality of the food products and dispose if necessary.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR 5 YEAR PARTS GUARANTEE ON 08448 24 24 24

7

Image 7
Contents FZS 175 Fzfm 151 Fzfm 171 Operating InstructionsAssistance Overall view Description of the applianceReversible doors Positioning and connection InstallationChanging the plug Precautions and tips Maintenance and careGB Start-up and use Disposal TroubleshootingRespecting and conserving the environment 195073402.04

FZFM 151 xx, FZS 175 xx, FZFM 171 xx specifications

Hotpoint is a well-known brand in the home appliance market, offering a wide array of refrigerators designed for efficiency, style, and user convenience. Among their popular offerings are the Hotpoint FZFM 171 xx, FZS 175 xx, and FZFM 151 xx models, each packed with features that cater to the modern consumer’s needs.

The Hotpoint FZFM 171 xx is a freestanding frost-free freezer that combines ample storage space with practical design. With a total capacity of around 171 liters, it provides ample room for all your frozen goods. This model features a contemporary white finish, making it suitable for various kitchen aesthetics. One of its standout technologies is the No Frost system, which prevents ice build-up and eliminates the need for manual defrosting, ensuring that your food is stored in optimal conditions.

Next in line is the Hotpoint FZS 175 xx, a larger model with even more storage capabilities. This freezer boasts a total capacity of approximately 175 liters and comes with multiple drawers for organized storage. The Smart Temperature Control technology ensures that the freezer maintains a steady temperature, even during power fluctuations. Additionally, its A+ energy rating signifies energy efficiency, minimizing electricity consumption while maximizing performance.

The Hotpoint FZFM 151 xx is another excellent option, featuring a combined fridge-freezer design. With a capacity of around 151 liters, it is versatile for those who need both freezing and refrigeration in one appliance. This model is designed with a reversible door for flexible installation, accommodating various kitchen layouts. The Super Freeze function is particularly useful for rapidly freezing fresh food, preserving nutrients and flavor.

All three models share common features, such as adjustable shelves, interior LED lighting for enhanced visibility, and an adjustable thermostat for easy temperature control. Designed with user-friendliness in mind, these freezers also prioritize energy efficiency to help reduce your carbon footprint. The robust build quality and thoughtful design of Hotpoint's freezer range ensure long-lasting performance and reliability.

In summary, the Hotpoint FZFM 171 xx, FZS 175 xx, and FZFM 151 xx models are exceptional choices for anyone in need of reliable and efficient freezing solutions, offering innovative technologies and features that enhance usability and storage efficiency in any modern kitchen.
