Installation

Mounting plate: DA 210-2

Mounting plate: DA 220-2

^Hold the mounting plate up to the ceiling so that the orange arrow faces the front of the hood and aligns with the line drawn on the ceilling.

Mark the position of the four mount- ing bolts a for securing the mounting plate and determining the position of the hole the power cord b will pass through.

Select the hole providing the shortest route for the power cable b to reach the power terminal located at the top of the hood’s chimney.

^Feed the ductwork and power cable through their respective holes in the ceiling.

If 6" (150 mm) ductwork is not possible then 5" (125 mm) ductwork can be used in conjunction with a reducing collar available from the Miele Technical Service Department (see "Installation / Air extraction" for further details).

^Drill four 3/16" (5 mm) holes in the ceil- ing.

The S10 wall anchors included in the packaging are not for use in USA/CDN. Be certain that the ceiling is stable enough to support the hood.

DA210-3 specifications

The Miele DA210-3 is a highly efficient and stylish range hood designed to enhance your kitchen experience while ensuring optimal air quality. Known for its German engineering and quality craftsmanship, this model embodies both functionality and elegance. One of its standout features is the effective airflow it provides, which is essential for maintaining a fresh cooking environment. With a maximum extraction rate of 650 cubic meters per hour, the DA210-3 efficiently removes cooking odors, smoke, and steam, allowing you to enjoy your culinary creations without lingering smells.

This range hood operates on a variable speed system, offering multiple intensity settings tailored to different cooking scenarios. Whether you're simmering sauces or frying meats, you can adjust the ventilation power to suit your needs. The intuitive control panel is designed for easy access, enabling quick adjustments even when you are busy in the kitchen.

One technological advancement of the Miele DA210-3 is the CleanCover feature, which is designed to improve safety and simplify cleaning. This integrated cover conceals the inner workings of the hood, preventing accidental touches to electrical components and creating a seamless appearance. Additionally, the stainless steel construction of the hood not only exudes a modern aesthetic but is also durable and easy to maintain, resisting fingerprints and smudges.

For those concerned with energy efficiency, the DA210-3 is equipped with an economical heat sensor that adjusts the fan speed based on the temperature detected, ensuring optimal performance without excessive energy use. The model also includes an efficient LED lighting system that illuminates the cooktop area, providing excellent visibility while cooking and enhancing the overall atmosphere of the kitchen.

Moreover, the Miele DA210-3 features a safe and efficient recirculation mode. You can choose to vent the air outside or keep it within your kitchen, using the highly effective filter system to purify it before reintroducing it into the room. The metal grease filters are dishwasher-safe, making maintenance a breeze.

In summary, the Miele DA210-3 combines powerful performance, sleek design, and innovative features. Its high extraction rate, variable speeds, easy-to-clean surfaces, and energy efficiency make it an excellent choice for any modern kitchen. Whether you're a casual cook or a culinary enthusiast, this range hood ensures that your kitchen remains a fresh and inviting space.
