Samsung RS2533 owner manual Select Button RS2555, RS2577, Soft Freeze, Chill, Cool

Page 11

CoolSelect ZoneTM Drawer GUIDE

“Select” Button (RS2555, RS2577)

Soft Freeze

When “Soft Freeze” is chosen, the temperature on the digtal panel displays -5oC regardless of the set tempera- ture of the refrigerator.

“Soft-Freeze” temperature helps keep meats and fishes fresh longer.

Can cut meat easily without drips.

Chill

When “Chill” is chosen, the temperature of the CoolSe- lect ZoneTM Drawer is kept at -1oC regardless of the set refrigerator temperature.

C

INSTRUCTIONS

“Chill” temperature helps keep meat or fish fresh longer.

Cool

When “Cool” is chosen, the temperature will be the same as the set temperature of the refrigerator. The digital panel shows the same temperature as that of the display panel.

For “Cool,” the CoolSelect ZoneTM Drawer allows extra refrigerator space.

OPERATING

11

Image 11
Contents Side by Side Refrigerator Other Signs Used Safety Warning SignsSafety Warning Signs Service center Setting UP the RefrigeratorMajor Features RS2533 RS2555, RS2577 Control PanelRS2533 Digital PanelPush the ice dispenser lever with a cup Temperature ControlCold Water Freezer Shelves and BinsFood Storage Guide Dairy Compartment Tempered Spill Proof Glass ShelfChilled Bin or CoolSelect ZoneTM Drawer Fruit & Vegetable Drawer Upper and LowerChill Chill temperature helps keep meat or fish fresh longerSelect Button RS2555, RS2577 Soft FreezeThaw Button Quick Cool ButtonRemoving the Freezer Accessories Beverage Stationtm RS2577 Cleaning the AccessoriesTwin Deodorizer Changing the Interior LightWater Filter Water Filter Indicator lightUsing the dispenser without the water filter Ordering replacement filtersSelecting the Location for the Refrigerator Installation of the RefrigeratorChecking the Dimensions of your Entrance Door Separating the Water Supply Line from the Refrigerator Removing the Refrigerator DoorsRemoving the Front Leg Cover Direction of the arrow Removing the Freezer DoorLift the door straight up Place doors on a protected surfaceRemoving the Refrigerator Door Hinge ➁ Connect the wiresReattaching the Freezer Door Insert the lower hinge ➀ in the bracket lowerFirst Reattaching the Refrigerator DoorsReattaching the Refrigerator Door It from the front part of the upper hinge coverReattaching the Front Leg Cover Reattaching the Water Supply Line➀ Driver Refrigerator If the door of the freezer is lower than thatChecking the Water Dispenser Line Installation of the Water Dispenser Line Installation of the Water Dispenser Line Troubleshooting

RS2555, RS2533, RS2577 specifications

The Samsung RS2577, RS2533, and RS2555 are part of Samsung's innovative line of side-by-side refrigerators that blend functionality with aesthetic appeal. Each model boasts a variety of features and technologies designed to enhance user convenience and maintain optimal food freshness.

The Samsung RS2577 is particularly known for its spacious interior, providing ample storage capacity with its 25 cubic feet design. It features a Twin Cooling Plus system that uses separate cooling systems for the fridge and freezer compartments, ensuring that food stays fresh longer by maintaining ideal humidity levels. The model also includes an ice and water dispenser conveniently located on the front, making it easy to access chilled beverages at any time. Additionally, the bright LED lighting illuminates the interior, allowing users to easily find items stored in the refrigerator.

Next, the RS2533 model offers a visually appealing finish that complements any kitchen décor. It features a sleek design alongside efficient storage solutions. The RS2533 utilizes the Multi-Flow Cooling system, which circulates cool air evenly throughout the refrigerator to maintain a consistent temperature. The model is equipped with adjustable shelving and crisp drawers to accommodate various food items, making organization easier. Energy efficiency is a notable characteristic, with this model earning an Energy Star rating, helping users save on electricity bills while being environmentally friendly.

Lastly, the RS2555 blends technology and style seamlessly. Highlighting a modern design, this refrigerator features a digital display control panel that allows users to easily adjust temperatures and settings. The model includes a powerful filtering system that improves water quality for the ice and water dispenser. Notably, the RS2555 also integrates a Smart Lock feature, ensuring that little hands can’t access the refrigerator without adult supervision, making it a great choice for families with young children.

In summary, the Samsung RS2577, RS2533, and RS2555 are designed to cater to a variety of preferences and requirements. With advanced cooling technologies, energy efficiency, ample storage options, and user-friendly features, these models exemplify Samsung's commitment to innovation in kitchen appliances. Each refrigerator stands out with its blend of functionality, aesthetics, and the ability to keep food fresher for longer, ultimately enhancing the user's kitchen experience.
