Water Filter, Removal and Installation | Dacor IF36, EF36 manual

WATER FILTER

REMOVAL AND INSTALLATION

WARNING

To avoid serious illness or death:

•Do not use refrigerator where water is unsafe or of unknown quality without adequate disinfection before or after use of filter.

•Systems certified for cyst reduction may be used on disinfected waters that may contain filter able cysts.

CAUTION

After installing a new water filter, always dispense water for two minutes before removing the filter for any reason. Air trapped in system may cause water and cartridge to eject. Use caution when removing.

•The bypass cap does not filter water. Be sure to have replacement cartridge available when filter change is required.

•If water filtration system has been allowed to freeze, replace filter cartridge.

•If system has not been used for several months, or water has an unpleasant taste or odor, flush system by dispensing water for two to three minutes. If unpleasant taste or odor persists, change filter cartridge.

Initial Installation

The water filter is located in the upper right hand corner of the fresh food compartment.

1.Remove blue bypass cap and retain for later use.

2.Remove sealing label from end of filter and insert into filter head.

3.Rotate gently clockwise until filter stops. Snap filter cover closed.

4.Reduce water spurts by flushing air from system. Run water continuously for two minutes through dispenser until water runs steady. During initial use, allow about a one- to two-minute delay in water dispersal to allow internal water tank to fill.

•Additional flushing may be required in some households where water is of poor quality.

Replacing Water Filter

IMPORTANT: Air trapped in system may cause water and cartridge to eject. Always dispense water for two minutes before removing the filter for any reason. Use caution when removing.

1.Turn filter counterclockwise until it releases from filter head.

2.Drain water from filter into sink, and dispose of filter in normal household trash.

3.Wipe up excess water in filter cover and continue with Initial Installation, steps 2 through 4.

The filter should be changed at least every 12 months.

Important: Condition of water and amount used determines life span of water filter cartridge. If water use is high, or if water is of poor quality, replacement may need to take place more often.

To replacement filter cartridges or for service, contact your local dealer or Dacor Customer Service, 1-800-793-0093. (U.S.A. and Canada)

The dispenser feature may be used without a water filter cartridge. If you choose this option, replace filter with blue bypass cap.

EF36, IF36 specifications

The Dacor IF36 and EF36 refrigerators represent the pinnacle of modern refrigeration technology, combining superior performance with elegant design. These models are celebrated for their innovative features, making them an ideal choice for any culinary enthusiast seeking both function and style in their kitchen.

One of the standout features of the Dacor IF36 and EF36 is their built-in design, allowing seamless integration into cabinetry for a streamlined appearance. This design not only enhances kitchen aesthetics but also offers convenience, as these units can be installed at optimal heights for easy access to all food items.

Both models boast advanced cooling technologies, including Dacor's signature Dual Cooling System, which maintains ideal humidity levels in the refrigerator while preventing odor transfer between compartments. This system promotes longer food preservation, ensuring your ingredients remain fresh longer. The refrigerators feature precise temperature control, allowing users to set ideal conditions for different types of food, enhancing their overall culinary experience.

The IF36 and EF36 utilize an intuitive touchscreen control panel, making it easy to adjust settings and monitor the internal environment effortlessly. This modern interface adds a sophisticated touch while providing essential information at your fingertips. Also notable is the Wi-Fi connectivity, which allows for remote monitoring and control via a smartphone app.

Another key characteristic is the energy efficiency of both models. They are designed to minimize energy consumption while maintaining peak performance, making them an environmentally friendly choice. With ENERGY STAR certification, users can rest assured they are investing in a product that is both sustainable and cost-effective.

The shelves in these refrigerators are designed with flexibility in mind. Adjustable and spill-proof glass shelving provides versatility for storing various food items while preventing messes. The integrated LED lighting illuminates the interior beautifully, ensuring visibility and easy access to items stored within.

Additional features include a robust ice maker for a constant supply of fresh ice, as well as a water dispenser providing filtered water on demand. The easy-to-clean finishes and materials used in the construction of Dacor IF36 and EF36 also make maintenance a breeze.

Overall, the Dacor IF36 and EF36 refrigerators are a testament to the perfect blend of innovation and style, offering groundbreaking features that enhance the user's cooking and food storage experience while maintaining a sophisticated presence in any kitchen environment.
