Grille installation

With the woofer baffle installed, and

the subwoofer tested, the grille can now be installed.

The grille assembly consists of the fol- lowing components:

The grille frame. This screws to the woofer baffle and holds the grille in place. It forms a nice frame around the subwoofer opening in the wall, hiding the sheetrock edges.

The grille. This pushes into the grille frame, covering the woofer baffle assembly and the grille frame screws from view.

A paint shield is supplied to cover the woofer baffle when painting.

This allows you to paint the frame and grille at the same time the walls are painted.

Painting

The frame and grille can be painted to match the decor before they are installed. They come already powder coated, and can accept a wide range of finishes.

Clean them first, then take them to a well-ventilated area and paint with care to achieve a good finish.

If you prefer to paint the frame and grille when they are in place on the walls, the details are shown on the next page.

Top view

Grille Install

Grille

Grille frame

Paint shield

18 User's Manual
