Frigidaire FRS6R4EB3, FRS6R5ESB7, FRS6R5ESB2, FRS23F5AB4, FRS23F5AB5, FRS23F5AW5 Looking Inside

Page 8

LOOKING INSIDE

PIZZA SHELF (SOME

MODELS)

This shelf is attached to the freezer wall beside the ice dispenser container. This convenient area allows for storage of pizza and other tall items placed vertically between the ice dispenser container and the freezer wall.

ICE CREAM SHELF (SOME

MODELS)

This shelf attaches to the top of the ice dispenser container. It allows storage of both round and rectangular cartons of your favorite ice cream.

TIP-UP SHELF (SOME

MODELS)

A Tip-Up shelf in the freezer section allows tall items to be easily stored.

Pizza Shelf

Ice Cream Shelf

CANTILEVER SHELF ADJUSTMENT

Refrigerator shelves are easily adjusted to suit individual needs. Before adjusting the shelves, remove all food. Cantilever shelves are supported at the back of the refrigerator.

To adjust cantilever shelves:

1Lift front edge up.

2Pull shelf out.

Replace the shelf by inserting the hooks at rear of the shelf into the wall bracket. Lower the shelf into the desired slots and lock into position.

*SpillSafeTM glass shelves (some models) catch and hold accidental spills. In some models, the * SpillSafeTM shelves slide out for easy access to food and for fast cleaning. The shelves slide out independently of their mounting brackets. Just pull the front of the shelf forward. Shelves can be extended as far as the stopper will allow but are not removable from their mounting brackets.

1

2

1

CAUTION

To avoid personal injury or property damage, handle

2



tempered glass shelves carefully. Shelves may break





suddenly if nicked, scratched, or exposed to sudden

Cantilever Glass Shelf

Cantilever Sliding Glass Shelf

temperature change.

DOOR STORAGE













Door bins and shelves are provided for convenient storage of

ADJUSTABLE DOOR BINS

jars, bottles, and cans. Frequently used items can be quickly

Some models have adjustable door bins that can be moved to

selected.







suit individual needs.

Some models have door bins that can accommodate gallon-

To move door bins

sized plastic drink containers and economy-sized jars and

containers. Some bins are adjustable for maximum storage

1.

Lift bin straight up.

capacity.



2.

Remove bin.







3.

Place bin in desired position.

The dairy compartment, which is warmer than the general food

4.

Lower bin onto supports until locked in place.

storage section, is intended for short term storage of cheese,





spreads, or butter.

Adjustable Door Bin

Fixed Door Bin

* WhiteWestinghouse - SpillFreeTM





8
