CDN-34S

RELAY PLAY

The cables required are commercially available 3.5mm (1/8”) mini-plug cables. One has already been included with your unit so the relay function could be used.

1.Connect auto start cable between both sides of the remote unit.

2.Insert CDs into both sides of the unit.

3.Hold down the time buttons for 1-2 seconds until the display indicates “auto” and the track number begins to flash. The track number will flash while the mode is active. Both sides must be active for relay to work.

4.Put both sides in SINGLE play mode while learning this function.

5. Press play on CD1 of the unit. When that CD1 has finished play it will send a signal to CD2 to start play. You will see CD2 start play and CD1 pause and cue to the beginning of the next track. When CD2 has completed play CD1 will start.

Note: The play command is sent at the end of specified play. If the unit is in SINGLE mode the play command will start at

the end of the track. If the unit is in CONTINUOUS mode the play command will be sent at the end of the full CD. Two

CDs will play continuously, alternating from side to side. This feature will also work in program mode, however, if the

sides are also in SINGLE mode the same number of tracks programmed should be the same. Play will stop at the end of

the last track.

FADER-START MODE

This mode is achievable by attaching both sides of your CD player to a similarly equipped DJ mixer.

1.Connect cables between the CD remote unit and your DJ mixer.

2.Hold down the time button for 1-2 seconds to activate the fader start capability.

3.Follow the directions in your mixer manual

Typically if you move the crossfader toward the active channel, the attached CD player will activate. When it is moved

away that side will cue, (similar to pressing the cue button).



- The Leader in DJ Technology



©1999 Numark Industries

- 12 -
