American Standard 2722W.202, 2722W.102 warranty General Specifications for 2722W Bathing Pool

Page 2

ROPE TWIST™

BATHING POOL

HIGH GLOSS ACRYLIC





60"







7-3/4"

(1524mm)





3/4"

(197mm)

FINISHED

70mm



(19mm)



WALL

(2-3/4)









15-1/8"









(385mm)













229mm x 305mm









(9 x 12)









FLOOR









CUTOUT





32"









(813mm)









25mm

4-1/2"





(1)

C/L OF

(114mm)







DRAIN















FINISHED









WALL

TOP OF



3-1/2"





DECK



(89mm)





1"









(25mm)





SEE

16-3/4"

17"









NOTE





(425mm)

(432mm)















2"

















(51mm)

4-5/8" (117mm)

BATH SUPPORT MATERIAL

ROUGH

FLOOR 1-1/2 N.P.T. THREADS

1-1/2 O.D. TAILPIECE

GENERAL SPECIFICATIONS FOR 2722W BATHING POOL

INSTALLED SIZE





















60 x 32 x 17 In.

























(1524 x 813 x 432mm)

WEIGHT



























60 Lbs. (27 Kg)

WEIGHT w/WATER















393 Lbs.(179 Kg)

GAL. TO OVERFLOW



















40 Gal. (151 L)

BATHING WELL AT SUMP







22 x 44 In. (559 x 1118mm)

BATHING WELL AT RIM









25.5 X 53 In.(648 x 1346mm)









WATER DEPTH TO OVERFLOW











10 In. (254mm)











FLOOR LOADING





29 Lbs./Sq.Ft. (195 Kgs/Sq.m)





(PROJECTED AREA)





















PTS.















15.3

CUBE (FT3)











27











NOTES:

BATH TO BE INSTALLED ABOVE FLOOR LINE AS A RECESS INSTALLATION.

REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.

LEFT HAND OUTLET SHOWN, RIGHT HAND REVERSE DIMENSIONS (2722W.202).

FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.

PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.

IMPORTANT: Dimensions of fixtures are nominal and may vary within the range of tolerances established by ANSI Standards Z124.1 and A112.19.7. These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.



H104



© 2008 AS America Inc.

Revised 3/08
