Bluetooth USB Combo Dongle

The Bluetooth USB Combo Dongle, BUD210 is a wireless device, which connected to the USB port of a PC/NB. It works automatically as your default sound card when plugged into your PC/NB. Just like a breeze, it will auto- matically search its Bluetooth counterpart, BSH201 /202/203 for auto pairing and connection. You just enjoy a quality stereo music sounds from your PC/NB. It can also

act as a data dongle for you to connect with other Bluetooth device when you installed the software. In the HCI mode, you can use Headset profile to connect with BSH203/BSR202 to chat with your friend thru MSN/Yahoo/Skype.

FEATURES

zAutomatically pairs with AV stereo headset, and connected in AV mode

zCould switch between AV and HCI mode automatically

zSupport variety of Bluetooth profile in HCI mode

zWindows 2000, XP compatible

SPECIFICATION













Standards



z Bluetooth specification V1.2 compliant









z Native Bluetooth A2DP profile









z Native Bluetooth AVRCP profile









Support following profile in HCI mode with soft-









ware install - GAP, DUN, OPP, HCRP, HID, PAN,









BIP, A2DP, AVRCP, SYNC, HSP, FAX, LAP, FTP















Frequency Band



2402 ~ 2480 MHz















Tx Power



0.25 ~ 2.5mW (Bluetooth Power Class II)















Rx Sensitivity



< -80dBm (PER 1%)















Distance



> 10m (open space)















Audio Streaming Format



SBC 48.000kHz















Audio Frequency Range



20Hz ~ 22kHz















Physical Specification:



z Dimension: 69.53 x 26.68 x 9.19 mm (LxWxH)









z Weight: 10g















Environmental Range:



z Operating temperature:-10 ~ +50









z Humidity: Relative humidity 0 ~ 95%















Certifications:



FCC, CE, BQB, TELEC













USER INTERFACE DEFINITION

LED

2005-05-12

Discovery: Green fast blinking

Connected: Green slow blinking

Page 1
Image 1
Abocom BUD210 specifications Bluetooth USB Combo Dongle, Features, Specification, User Interface Definition

BUD210 specifications

The Abocom BUD210 is a sophisticated network device designed to meet the diverse needs of modern communication. Primarily known for its robust capabilities in providing high-speed broadband access, this device is ideal for both residential and small to medium-sized business environments.

One of the standout features of the BUD210 is its support for various advanced connectivity technologies, including xDSL and fiber optics. This versatility enables users to achieve high-speed internet connections regardless of the underlying infrastructure. The device can seamlessly integrate with existing network architectures, ensuring minimal disruption during setup.

The BUD210 is equipped with multiple Ethernet ports, allowing for both wired and wireless connections. This feature is especially beneficial for users who require stable internet access for multiple devices simultaneously. The Ethernet ports support Gigabit speeds, ensuring data transfer occurs without bottlenecks, which is essential for activities like video streaming, online gaming, and large file transfers.

Security is a top priority for the Abocom BUD210. The device comes with robust security protocols, including WPA3 encryption, ensuring that users' data remains safe from unauthorized access. Additionally, it includes built-in firewall capabilities, providing an extra layer of protection against potential external threats.

Another impressive aspect of the BUD210 is its user-friendly interface, which simplifies the process of network management. Users can easily configure settings, monitor performance, and troubleshoot issues through an intuitive web-based management portal. This feature is particularly useful for non-technical users who need to manage their networks without extensive technical knowledge.

The BUD210 also supports Quality of Service (QoS), allowing users to prioritize certain types of traffic. This is crucial for maintaining performance during peak usage times, ensuring that critical applications receive the bandwidth they require for optimal performance.

Overall, the Abocom BUD210 is a feature-rich device designed to deliver reliable internet access while addressing the growing demands of users. Its combination of speed, security, and ease of use makes it a compelling option for anyone looking to enhance their network capabilities. Whether for home or office use, the BUD210 stands out as a versatile solution to contemporary connectivity challenges.
