Bottom Front

Bottom Back

Tower Power LED

Power Switch

eSATA Port



Connecting Data Cable from the Tower to the System

Note: It is required that the Optical tower V be connected to a port multiplier compatible eSATA host controller for the system to see all nine optical drives. It is assumed that the driver for the eSATA host controller is correctly installed.

a.Using an eSATA to eSATA cable, connect one end to the eSATA port on the tower and the other to the eSATA port on the system.

Connecting the Power Cable and Turning on the Optical Tower V

a.Connect the power cord provided from the wall outlet to the back of the tower.

b.A main power switch is located on the front of the tower.

Sharing the Optical Drives in Windows

Right click the drive in My Computer, select Sharing, Select Advanced Sharing, share it and set the permissions (full control).

CONTACT US

www.addonics.com

Phone: 408-573-8580

Fax: 408-573-8588

Email: http://www.addonics.com/sales/query/

Page 2
Image 2
Addonics Technologies ST5DVRE Connecting Data Cable from the Tower to the System, Sharing the Optical Drives in Windows
