C

H

COLONY SOFT

TWO-HANDLE CENTERSET LAVATORY FAUCET

MODEL NUMBER:

2275.403 Centerset Lavatory Faucet

Clear Acrylic Handles. Non-metalic Speed Connect™ Pop-up drain.

2275.409 Centerset Lavatory Faucet

Clear Acrylic Handles. Metal Speed Connect™ Pop-up drain.

2275.400 Shown.

HOLE SIZE

29mm (1-1/8")

102mm











107mm











(4")





(4-3/16")

















41mm

(1-5/8")



1/2 NPSM

22mm



(7/8")



28mm

107mm

(1-1/16")

(4-3/16")

154mm

(6-1/16")

32mm OD (1-1/4 OD)

GENERAL DESCRIPTION:

PRODUCT FEATURES:

Centerset lavatory faucet on 4" centers. 1/4 turn washerless ceramic disc valve cartridges. Durable cast brass waterways with one-half inch male inlet shanks. Metal body. 20" (500mm) long flexible stainless steel drain cable is pre-assembled to faucet body. Metal Speed Connect™ drain body with 1-1/4 inch (32mm) tail piece, (2275.409). Non-Metallic Speed Connect™ drain body with 1-1/4 inch (32mm) tail piece, (2275.403). 2.2 gpm/8.3L/min. maximum flow rate. Clear Acrylic Handles are facetted on the inside.

Cast Brass Waterways with "City Shanks": Strong and durable. Integral tabs on casting provide a wobble-free installation.

Ceramic Disc Valve Cartridges: Assures a lifetime of smooth handle operation and drip-free performance. Reversible for use on either "hot" or "cold" side.

Low Lead: Meets NSF Standard 61/Section 9 & Prop 65 lead requirements.

Speed Connect™ Drain:

• Fewer parts. Installs in less time.

• No adjustments required - seals the first time, every time.

• Flexible stainless steel cable - installs effortlessly in tight spaces. Longer Spout: Provides extended reach into lavatory.

Simple Installation: Fast and easy one person installation. Faucet drops in from top. Quick spin nuts secure faucet in place.

SUGGESTED SPECIFICATION:

Two-handle 4" centerset lavatory faucet shall feature a cast brass waterway. Shall also feature 1/4 turn washerless ceramic disc valve cartridges. Shall also feature a drain body with stainless steel cable actuation. Fitting shall be American Standard Model # 2275.40__.____.

C99

© 2006 American Standard Inc.

Page 1
Image 1
American Standard 2275.40 manual TWO-HANDLE Centerset Lavatory Faucet Model Number, General Description

2275.40 specifications

The American Standard 2275.40 is a standout model in the realm of bathroom fixtures, specifically designed to enhance user comfort and efficiency. This toilet model embodies the perfect blend of modern technology and classic design, ensuring that it appeals to various customer preferences while maintaining superior functionality.

One of the primary features of the American Standard 2275.40 is its innovative flush system, which utilizes the company’s renowned “PowerWash” technology. This powerful flush mechanism ensures that every flush is thorough, effectively cleaning the bowl and reducing the necessity for frequent maintenance. The integrated bowl cleaning system not only prevents buildup but also contributes to water conservation by using only 1.28 gallons per flush, which meets the EPA WaterSense criteria for eco-friendly performance.

Another notable characteristic is its comfortable height design. The toilet sits at a higher profile, providing ease of use, especially for individuals with mobility struggles or those who prefer a more accessible option. Coupled with the ergonomic seat design, users can enjoy an enhanced experience without sacrificing style.

The American Standard 2275.40 also boasts a sleek and stylish aesthetic. With a range of finish options, it can seamlessly fit into any bathroom decor, from contemporary to traditional themes. The smooth lines and modern curves not only offer elegance but also make cleaning simpler, as fewer crevices trap dirt and grime.

Moreover, this model is constructed with high-quality materials that ensure durability and resilience. The porcelain finish is both stylish and practical, resisting chipping and staining over time. This durability means reduced maintenance and longevity in use, making it a wise investment for homeowners and businesses alike.

Installation of the American Standard 2275.40 is straightforward, with a standard height that allows for compatibility with various plumbing systems. This ease of installation contributes to its popularity among contractors and DIY enthusiasts.

In conclusion, the American Standard 2275.40 combines cutting-edge toilet technology with user-centered features, making it a top choice for those looking to upgrade their bathroom fixtures. Its efficient flushing system, exceptional design, and commitment to water conservation highlight its standing as a leader in the market. Whether for residential or commercial use, this toilet model promises a high level of satisfaction and performance, aligning with American Standard’s reputation for excellence.
