	Installation
TOWN SQUARE	Instructions
ACRYLIC SHOWER BASE

MODELS 3636.STTS, 3838.NEOTS, 4834.STTS

Thank you for selecting American-Standard...the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--please read these instructions carefully before you begin.

For alcove (.STTS models) installation only: The opening dimensions should be 1/8" larger than dimensions shown.

Certified to comply with ANSI Z124.2 1987. Observe local plumbing and building codes.

7 5 2 7 6 9 - 1 0 0

NOTE: Read instructions completely before proceeding with installation.

3838.NEOTS

484mm (19-1/16)

679mm

(26-3/4)

4834.STTS

FRONT

870mm

3636.STTS

FRONT

972mm

(38-1/4)

215mm

(8-7/16)

215mm

(8-7/16)

972mm

(38-1/4)

(34-1/4)

215mm

(8-7/16)

484mm

(19-1/16)

610mm

(24)

1219mm (48)

914mm

(36)

215mm

(8-7/16)

457mm

(18)

914mm

(36)

1

Insure the floor and stud walls are square and plumb. Provide a 5" x 5" (127mm x 127mm) opening in the floor for the drain (see Figs. A & B). The drain plug accom- modates a 2" (51mm) PVC waste pipe. The waste pipe should extend above the surface of the sub- floor 3/8" ± 1/16". Note: Variations in levelness of subfloor may require adjustment of waste pipe height. See product drawings on this page for the specified drain locations.

3838 NEOTS			2
90°	C/L	C/L	90°
	51 mm (2)	127mmx127mm
PVC Waste Pipe
		(5x5) Opening
A (See Product Chart for Drain Location)
3636.STTS, 4834.STTS

90°90°

51 mm (2)	C/L 127mmx127mm
PVC Waste Pipe	(5x5) Opening

B(See Product Chart for Drain Location)

	DRAIN
	ASSEMBLY
Before installing drain		Strainer
	Rubber
into the shower base,	Caulking
remove strainer (see Fig.	Gasket
C). This will be installed	Drain
after shower base is in
	Body
its final position. Install
	Silicone	Shower
the drain to the shower
	Sealant	Base
base as shown in Fig. D.
Use silicone sealant
between drain body and	Rubber	Fiber
shower base.	Gasket	Gasket

		Locking
		Nut
	C
	Waterproof
	Drywall	3 mm
	13mm (1/2")	(1/8)
No Bedding	minimum
	Bedding Material Area
Under
Apron
Bedding	51 mm (2)
	PVC Pipe	51x102 mm
Material
	127 mm (5)
D		(2x4) Stud Wall

3

After leveling base on subfloor, use base and mark studs. This will be the installed height of shower base. Mix the low-shrink bedding material (grout, mortar, plaster, etc.). Concrete is not recommended. Apply enough bedding material to support the entire bottom of the shower base. The bedding material must not be used under the apron (front edge).

Lift and lower base over center

E of drain pipe and set into place
