M1000

Features

M1000 Masking Speaker

With a good majority of America’s workplaces having adopted an open office plan, favoring a labyrinth of cubicles over traditional closed offices, conversational privacy has become an increasingly sensitive issue. A properly designed sound masking system can significantly increase speech privacy and improve the overall work environment.

The new M1000 masking speaker assembly is designed to accurately reproduce the needed spectrum of masking signal into the plenum space. The innovative 734 cubic inch square enclosure ensures ample low frequency response. A specially designed 8" dual cone loudspeaker is included in the package. A high efficiency 70.7V internal transformer is coupled to an external selector switch for easy system tuning. For more precise adjustments, a wide

selection of wattage taps ranging from, 14 watt to 4 watts plus off are provided.

The exclusive Atlas Sound EZ hang brackets simplify installation. This innovative suspension system utilizes (2) collapsible galvanized hangers configured to allow quick upward or side firing installation. The hangers are factory- installed on the unit and fold flat for shipping. To meet most any local code requirement, the M1000 includes an innovative cover containing both knockouts and a strain relief. This system will allow the use of rigid or flexible conduit (if required) and easily accommodates "through" connections on the removable plate. To fit continually shrinking construction budgets, the M1000 is very aggressively priced. Contact your regional Atlas Sound representative for details.

Pre-Assembled Unit Includes 8" Dia. Loudspeaker, Transformer, Enclosure, Baffle and Mounting Hardware

Labor-Saving Hardware Package – Complete with New Snap Hanger Assembly, Allows Quick and Easy Installation

Innovative Input Panel Includes Combination Knock-out and Strain Relief Connector to Accommodate Flexible or Rigid Conduit

Design Enables Upward or Horizontal Sound Dispersion

734 Cubic Inch Enclosure for Extended Low Frequency Response

Black Epoxy Finish Blends with Open Ceiling Plans

Suitable for Use Above Suspended Ceiling Systems

UL 1480 & 2043 Listed









SPECIFICATIONS







MODEL

LOUDSPEAKER

MAGNET WEIGHT

TRANSFORMER TAPS

ENCLOSURE

SOUND DISPERSION

WEIGHT









VOLUME

DIMENSIONS





M1000

8" DUAL CONE

10 oz. (260g)

off, .25,

.5, 1, 2 and 4

119/16"L x 119/16"W X 51/12"H

Upward, Downward

9 Lbs.









734 Cubic in.

and Horizontal

3.4 kg.









(243 X 243 X 140MM)



















• Five Year Limited Warranty •





1601 Jack McKay Blvd.

Ennis, TX 75119

AtlasSound.com

Tech Support 1.800.876.3333

Printed in the USA





Specifications are subject to change without notice.



©2004 Atlas Sound LP. Atlas Sound is a trademark of Atlas Sound LP. All rights reserved.

484077

000904

ATS001157 RevB 9/04
