Bakers Pride Oven Y-602 specifications Specifications, Standard Features, Options & Accessories

	SUPER DECK
BAKERS	Y SERIES
	GAS DECK OVENS
PRIDE

Model Y-602

with optional casters

SPECIFICATIONS

BAKERS PRIDE Super Deck Y-Series gas Deck Ovens are designed for high volume pizza and all-purpose operations.

Ovens may be stacked two high. Oven exteriors are all heavy- gauge, type 403 stainless steel and are fully insulated up to 5" (127mm) thick for cooler outer temperatures and consistent interior temperatures.

Interior oven frame is constructed of 1/4" (6mm) heavy-duty angle iron frame, completely welded to form a single, unitized section. The oven body and lining are then welded to the framework.

Oven interiors are manufactured of high-heat resistant 16-gauge aluminized steel. Doors are fully insulated, spring balanced with tubular steel handles and will remain open or closed until moved.

All models feature independent, operator-controlled top & bottom heat control dampers and micro slides for perfectly balanced results.

Y Series features a 300°-650° F (149°-343°C) throttling thermostat, 8" (203mm) interior deck height with 1 1/2" (38mm) thick hearth baking decks (steel decks optional) and are supported by a 1/4" (6mm) angle iron frame.

Combination gas control incorporates a manual gas valve, pilot safety and pressure regulator. Easily removable, slide-out, heavy- duty flame diverters distribute the burner flame uniformly in the burner chamber. A 3/4" (19mm) NPT gas connection is located on the left side and left rear of oven - operator/installer may choose.

Heavy-duty, 7-gauge hot rolled steel legs are standard and finished with durable Bakertone.

2 Year limited part and labor warranty standard.

Job ____________ Item # ___________

GAS DECK OVENS G

￿Model Y-600 Single

￿Model Y-602 Double

￿Model Y-800 Single

￿Model Y-802 Double

STANDARD FEATURES

￿Y Series @ 120,000 BTUH per deck, natural or LP gas — CE not available in LP gas

￿300°-650° F (149°-343°C) throttling thermostat

￿Top & bottom heat control dampers & micro-slides

￿Combination gas controls with valve, regulator & pilot safety

￿Heavy-duty, slide-out flame diverters

￿8" (203mm) interior deck heights with 1 1/2" (38mm) thick hearth stone baking decks

￿All stainless steel exteriors

￿Aluminized steel interiors

￿Spring balanced, fully insulated doors

￿Side or rear gas connections

￿7-Gauge legs

￿Fully insulated throughout

￿2 Year limited part and labor warranty

OPTIONS & ACCESSORIES

￿Side-mounted controls

￿Steel decks

￿Light stone decks

￿150°-550° F (65°-288°C) thermostat

￿Set of 4 casters - two with locks

￿Stainless steel leg covers

￿Special height legs

￿Steam Injection

￿Automatic oven starter

￿Draft flue for direct vent (not available on CE units)

￿Fire brick hearth decks (Y-600/602 only)

￿Black powder-coated bake chamber and combustion chamber doors with hardwood handles

￿Black powder-coated hinged control panel door

￿DSP style - apply stone or tile finish directly to oven exterior - skirts provided

CERTIFICATIONS

	DESIGN
®	CERTIFIED
	CERTIFIED

BAKERS PRIDE OVEN COMPANY, INC.

30 Pine Street, New Rochelle, NY 10801

BAKERS 914/576-0200 • 1-800-431-2745 • fax 914/576-0605 PRIDE www.bakerspride.com

Continuous product improvement is a policy of Bakers Pride Oven Company. Therefore, specifications and design are subject to change without notification
