SOLO 3.4
Por t able power
GENERAL SAFETY INFORMATION
This manual contains important information about the assembly; use and maintenance of this product. Keep this manual for future reference. Be sure to read this manual completely before using the Solo. Keep this manual and review it regularly to maintain awareness of procedures and warnings.
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
1.USB DC Adapter (vehicle adapter)
2.USB AC Adapter (wall adapter)
3.Retractable input/output cord
4.Nokia adapter
5.Ipod adapter
6.Mini USB adapter
7.Motorola adapter
8.Sony Ericson Adapter
Charging the SOLO 3.4 with USB AC Adapter
1.Plug the Mini USB adapter into the retractable input/ output cord
2.Plug the Mini USB adapter into the IN port of the SOLO 3.4
3.Plug the USB end into the USB AC ADAPTER
4.Plug the AC adapter into the wall to charge
To outlet
To SOLO 3.4
The light on the SOLO 3.4 will turn RED. This indicates the SOLO 3.4 is charging. When the light turns GREEN, charging is complete.
Charging the SOLO 3.4 with USB DC Adapter
1.Plug the Mini USB adapter into the retractable input/ output cord
2.Plug the Mini USB end into the IN port of the SOLO 3.4
3.Plug the USB end into the USB DC ADAPTER
4.Plug the DC adapter into a vehicle adapter (cigarette lighter)
The light on the SOLO 3.4 will turn RED. This indicates the SOLO 3.4 is charging. When the light turns GREEN, charging is complete.
to vehicle adapter
To SOLO 3.4
Charging the SOLO 3.4 by USB (computer)
1.Plug the Mini USB adapter into the retractable input/ output cord
2.Plug the Mini USB end into the IN port of the SOLO 3.4
3.Plug the USB end into a USB port
The light on the SOLO 3.4 will turn RED. This indicates the SOLO 3.4 is charging. When the light turns GREEN, charging is complete.
Charging electronics (cell phone, Ipod, etc)
1.Plug the chosen adapter into the retractable input/ output cord
2.Plug the USB end of the retractable cord into the out port of the SOLO 3.4
3.Plug the chosen adapter end into the electronic you are trying to charge
4.Push the ON button. The light will turn green, indicat- ing the electronic piece is charging. When the GREEN light begins to flash, the battery level is getting low, recharge the SOLO3.4.
SOLO 3.4 SPECIFICATIONS
Battery type | Lithium Polymer |
Output Voltage | 5V (USB compatible |
Output Current | 3400mAH |
Capacity | 3.4 amp hours @ 5.5 volts |
Output port | Standard USB |
BRUNTON, Limited Warranty
Brunton warrants this product to be free of defects in materials and workmanship, for a period of one year. This warranty extends to the original purchaser for one year from the date of purchase.
This Warranty is void and a charge for repair will be made if the Solo has
BRUNTON Solo 3.4 Warranty Registration
Detach and Return within 30 days of purchase
Name: _____________________________________________
Address: ___________________________________________
City: _________________ State: _______ Zip: ______________
Phone: ____________________________________________
To SOLO 3.4
To iPod
Input port | Mini USB |
Dimensions | 3” x 4.12” x 0.75” |
Weight | 5.2 ounces |
Disposing of your SOLO 3.4
been damaged by negligence, accident or mishandling, or has not been operated in accordance with standard operating procedures, or if the Solo was altered or repaired by other than a Brunton repair facility.
This warranty gives you specific legal rights, and you also have rights, which vary from state to state. No other warranty, expressed or implied, applies to
Date Purchased: _____________________________________
Amount Paid: _______________________________________
Would you like to receive a Brunton Catalog? ( )Yes ( )No
Please let us know where you purchased your Solo
Store Name: ________________________________________
To SOLO 3.4
To PHONE
• Do not incinerate or dispose of your SOLO 3.4 in a fire |
or microwave. |
• Do not dispose of your SOLO 3.4 as ordinary refuse. |
• Consult your local municipal or civil authority for |
instructions on correctly disposing of a |
the Brunton product, nor is any person or company authorized to assume any other warranty for Brunton. Brunton does not assume any responsibility for any consequential damages occasioned by this product. Should the prod- uct prove defective, contact Brunton, and you will be provided with a Return Authorization Number (RA#). Send a copy of your proof of purchase, the
City: _________________ State: _______ Zip: _____________
( )
( ) Gift ( ) Brunton ( ) Other _____________________
Do you own another Brunton Product?
( ) Yes. Product: _____________________________ ( ) No.
SOLO 3.4 CHARGE TIMES
Cell phone | Run/Charge |
PDA | Run/Charge |
Digital camera | Charge |
MP3 player | Run/Charge |
Portable video games | Charge |
Digital camcorder | Charge |
Portable DVD player | Charge |
Battery Pack. |
Common Troubleshooting Steps
1.
2.Charge the Battery Pack.
3.Test the Battery Pack on another USB device.
RA#, a short description of the problem and the product to Brunton at the following address. Brunton suggests insuring the product in case of damage or loss in shipment.
Brunton |
|
Warranty Repair | (307) |
2255 Brunton Court | support@brunton.com |
Riverton, WY 82501 | www.brunton.com |
I decided to buy this product because of ...
( ) Features | ( ) Gift | ( ) Recommendation |
( ) Magazine | ( ) Catalog | ( ) Store Display |
( ) Salesperson |
| ( ) Newspaper |
This Solo will be used for ... |
| |
( ) Camping | ( ) Occupation | ( ) Sporting Events |
( ) Vacation | ( ) Travel | ( ) Education |
( ) Other: __________________________________________
