パソコンRS232C端子 (シリアルポート)へ

データ転送していなくても、電源スイッチがONになっていると電力を消費し、電池の寿命が短くなりま す。使用しないときはスイッチをOFFにしてください。

電池の寿命はアルカリ電池の場合で約50時間です。電源スイッチをONにしてもインジケータが点灯 しないときは電池を交換してください。

パソコンとの接続

インターフェイスユニットのケーブルをパソコンRS232C端子(シリアルポート)に接続します。

・ 接続はしっかり行ってください。接続が不確実な場合、転送がうまくできないことがあります。

・ ケーブルのコネクターは9ピンのシリアルコネクターです。IBMおよびIBM互換機に対応します。お使 いのパソコン機種によっては別途変換アダプターが必要となります。

MSCユニットの装着

1.MSCユニットをインターフェイスユニットのダウンロードステージに装着します。

図のように先に1MSCユニットの後方をフックにひっかけ、2前方を押し込みます。カチッと音がし てMSCユニットが固定されます。

2.インターフェイスユニットの3電源スイッチを入れ、インジケータの点灯を確認します。 以上でインターフェイスユニット側の準備は完了です。

外し方

ダウンロード終了後は電源スイッチを切り、開放ボタンを押すとMSCユ ニットがポップアップしロックが解除されます。

開放ボタン

インジケーター

フック

電源スイッチ

ダウンロードステージ

e-Train Data™ 9
