Christie Digital Systems LW40U manual P L I C At I O N S

•True WXGA resolution (1366 x 768)

•4000 ANSI lumens maximum

•DTV & HDTV compatible

•Progressive scan video decoding

•Motorized zoom, focus & lens shift (up/down)

•2 lamp system - dual or single lamp operation

•Lamp redundancy and failsafe operation

•Monitor lamp usage

•Extensive optional lens suite

•Presentation support features

A P P L I C AT I O N S

• Boardrooms,	• Auditoriums and
conference rooms	churches
• Training rooms,	• Casinos, theme parks
classrooms	and museums

Native Widescreen Projector Offers Ideal Display for 16:9 and XGA Images

Christie's LW40U is the new benchmark for native widescreen displays and the ultimate in video presentation.

With a true 16:9 aspect ratio and the visual power of 4000 lumens, the LW40U displays native HD content in its purest form and expands the capability of your presentations. Images have the “impact” factor of widescreen format without compromising image area or screen brightness.

The native WXGA panel provides 44% more pixels on the screen than an XGA resolution projector displaying 16:9 content. When displaying computer or data presentations, the image can be centered on the screen in pixel-perfect XGA (1024x768) mode without changing the zoom lens or cropping the image mode.

The latest 3D digital video processing produces sharp video images from analog and digital sources. A 90% brightness uniformity and a 900:1 contract ratio take your images to a higher level of presentation.

The dual lamp design gives you the confidence of guaranteed performance. The LW40U provides the option of projecting the full 4000 ANSI lumens for bright, large screen images or 2,400 ANSI lumens in single-lamp mode, to extend the life of the lamp.

Feature-rich and supported by a full suite of optional lenses and accessories for the ultimate presentation flexibility and control, the LW40U is compatible with Christie's Real Color Management (RCM) software. Users can target and match the displayed color to specific gamma curves and reference monitors for picture-perfect presentation and real-life images.

Compatible with a broad spectrum of analog and digital video and data inputs with a range of optional interface cards including DVI-D, SDI and HD-SDI formats to interface perfectly with the latest source players and receivers. Network connectivity is available through ChristieNET ™ to attach the LW40U to any network to monitor lamp life, projector temperature and other vital functions for full control and monitoring for preventative maintenance in real time.
