Coleman 2000004674 Things You Should Know:

Fig. 18

Self-rolling Windows

CAUTION: “Springs” may have sharp edges. Handle with care to avoid injury.

Keep out of reach of children.

NOTE: Carefully unroll metal “springs” stored in bag with stakes. The color

marking on each “spring” should match the color of the fabric “flag” sewn to

the window or door sleeve opening. (Fig. 19)

1. Locate sleeve(s) in window panel, open hook & loop fastener; then insert

“spring(s)” with matching color marking. (Fig. 19 & 20)

NOTE: When inserting into the sleeve(s), the

color marking on the “spring(s)” should always

face the operator.

2. Close hook & loop fastener to secure.

3. Before unzipping and opening the window, push in

at top to engage “spring(s)” to activate the

self-rolling feature. (Fig. 21)

4. Unzip to allow the window panel to roll down

automatically; zip back to close window panel. (Fig.

22 & 23)

NOTE: Repeat steps above for inserting the color

matching “spring(s)” into sleeve(s) for the rest of

the windows.

Fig. 19

Sleeve

Color “Flag”

STITCH LINE

4010006301 (20090910)

Things You Should Know:

Under certain conditions (cold weather, high humidity, etc.) •

condensation will form on the inside of your tent. Condensation is

caused by water vapor from your breath, perspiration, or any wet

clothing inside the tent. It is NOT LEAKAGE through the shelter fabric.

It can be minimized by removing wet clothing from your shelter and

by providing good ventilation through the tent.

Tree limbs, tree sap, bird droppings, or moisture steadily dripping •

off tree limbs can cause damage to the tent fabric and its coating

resulting in leaks or loss of ﬂ ame-resistant properties.

Never store tent, even for a short period of time, without drying it •

thoroughly and brushing off caked dirt. Do not pack stakes or poles

inside your tent. Use a separate storage bag.

Stakes should be removed by pulling on the stake itself. NEVER •

PULL ON THE TENT TO REMOVE STAKES AS THIS COULD RESULT IN

PROPERTY DAMAGE OR PERSONAL INJURY.

Tent poles should not be left telescoped together during storage.•

Do not leave your tent set-up for weeks at a time. Be aware that •

exposure to ultraviolet rays from the sun can seriously damage

material and/or cause it to become discolored.

WARNING: Keep all  ame and heat sources away from this

shelter fabric.

This shelter meets the flammability requirements of CPAI-84. The fabric may burn

if left in continuous contact with any flame source.

The application of any foreign substance to the tent fabric may render the flame-

resistant properties ineffective.

9. Extend out vestibule ﬂ aps and secure with metal stakes through the

loops in the web straps. (Fig. 18 & 18A)

10. Stretch guylines until taut, then secure with stakes. (Fig. 18 & 18B)

18A

18B

Self-rolling Windows continued

CAUTION: All “springs” must be removed from sleeves before tearing down

tent to avoid damage to the tent fabric or part. To avoid injury, carefully roll

up “springs”. Keep out of reach of children. Store rolled “springs” in bag

with stakes.

Cooler Access

The smaller zippered opening at the side of tent is

designed for added ventilation and easy access to

your beverage cooler.

1. To use as a vent, unzip ﬂ ap to expose screen.

2. To use as a cooler access, unzip other ﬂ ap to

make an avenue to bring beverages into tent. (Fig. 25)

To Store

1. All “springs” must be rolled up and placed in bag with stakes.

2. All poles and stakes must be placed in the storage bag to prevent dam-

age to the fabric items placed in the carry case.

3. Make sure tent is clean and dry before placing in carry case.

4. Remove rainﬂ y, spread out on ﬂ oor of tent, then unzip door & vents

before taking tent down for storage.

5. Neatly fold tent to width of pole storage bag, place on tent, roll tightly,

and place in carry case.

6. Store in a clean, dry area.

Electrical Cord Access

1. Unzip the access panel in the lower left

corner of tent and bring in an electrical

cord.

NOTE: Use only UL approved cords

rated for outdoor usage. (Fig. 24)

Fig. 25

Fig. 24

Door

Window

Panel

Window Panel

Push in at top

to engage

“spring(s)”

Fig. 21

Sleeves

Fig. 22

Fig. 23

Color

Dot

Fig. 20

Color

“Flag”

To Attach Rainfly continued

5. Insert end of each grey Rainﬂ y Pole into pin on either side of front door.

(Fig. 14)

6. Go to opposite end of Rainﬂ y Pole and gradually apply pressure to form

an arch. Insert the pin into pole end at other side of the door. (Fig. 14)

7. Locate all hook & loop fasteners on underside of Rainﬂ y and wrap around

all Main Poles, Awning & Rainﬂ y Pole to secure. (Fig. 15)

NOTE: Make sure longer hook & loop fastener on Rainﬂ y is secured

around grey and black Main Poles where they cross. (Fig. 16)

Fig. 14

Fig. 15 Fig. 16

8. Stretch elastic straps and hook clip on each to

the metal loops at the front and back corners

of the tent. (Fig. 17)

Fig. 17

(continued)
