Compaq warranty Overview, Compaq Netelligent 5226A Ethernet Switch

OVERVIEW

Compaq Netelligent 5226A Ethernet Switch

B E N E F I T S A T

AG LANCE

•VLAN allows users to configure useful VLAN environments from the perspective of broadcast control, network segmentation and network security issues

•Remote monitoring (RMON) gives the management system the capability to remotely monitor the switch for diagnostic purposes

•Multiple high-speed uplink ports provide high-speed connections (TX and/or FX) to backbones, servers, or other 100 Mb/s devices

•10/100Base-TX ports are dual speed and auto- sensing to provide flexibility in connectivity

•ASIC-based design means that switching instructions are implemented in hardware rather than firmware—providing higher performance, reliability and lower cost

•Full duplex support on every port increases network transfer rates up to 20 Mb/s on 10Base-T ports and 200 Mb/s on 100Base- TX and 100Base-FX ports

•VT-100 serial port/Telnet Management for managing the switch over the LAN or via the Internet

•Spanning Tree support allows set up of redundant links for maximum up-time

•Netelligent Management Software is included to help users manage their network

•Three-year limited warranty1

1Certain restrictions and exclusions apply. Contact Compaq Networking Products Division Sales at 1-800-544-5255 or the Compaq Networking Technical Support Center (post sales) at 1-800-386-2172 for details.

...........................................................................................................................................................................................

..........................

6-85

- - - -

1.Link, Activity, and Collision LEDs

2.Power “A” On Indicator

3.Modular Port Insert and Activity LEDs

4.Fixed 10/100Base-TX Port Link, Activity, Collision and 100TX LEDs

5.Power “B” On Indicator

6.Fixed 10Base-T Ports

7Fixed 10Base-T PortsFixed 10/100Base-TX Ports

8.Empty Slot for Optional Redundant Power Supply Module

9.Serial Com Port

10.Modular Power Supply

11.Empty Slot for Optional 2-port Fast Ethernet Uplink Module
