QuickSpecs

Compaq Premier• Sound

PS115 Speakers

MODELS

Compaq Premier• Sound™ PS115 Speakers

133566-022

The Compaq Premier• Sound PS115 Speakers offer users a compact, high-end sound solution.

OVERVIEW

Compaq Premier• Sound PS115 Speakers offer users a compact, superb multimedia solution, providing crisp, clear highs, warm midranges and clean robust basses for an impressive stereo sound experience.

This product is for users who need a more robust sound solution than a standard integrated desktop speaker. Specifically, this audience ranges from mainstream application users to advanced film, video, and high-end post-production, to game developers and graphic designers.

Target Audience

The Compaq Premier• Sound PS115 Speaker system is targeted for both home and business users who need and want a more robust sound solution. Specifically, this audience ranges from mainstream application users to advanced film, video, and high-end post- production, to game developers and graphic designers.

Performance

The Compaq Premier• Sound PS115 Speakers are designed to exceed the customer’s expectation of audio quality in small, compact, cost-effective loudspeakers using the following advanced technologies:

•Wide frequency bandwidth down to 75 Hz allows for controlled, smooth, hi-fi like bass

•An amplifier capable of transmitting 18 W per channel so that distortion is controlled at both typical as well as low frequencies levels that require more power

•Transducer or speaker drive transforms the electric signals and delivers lower frequency output by lengthening the voice coils, increasing magnet size, and enhancing the power handling capability

•Bass reflex loudspeaker enclosures contain the transducers and amplifiers and are specifically designed to enhance the bass output in a small space

•The 10 stages of fixed equalization “shape” and “push the music back” so that a listener sitting 2-3 feet away is not blasted by the music, but rather hears a natural sound reproduction.

Key Features

•Attractive, slim form factor with cloth grille

•Tone Control (loudness control) – User is able to optimize system’s performance and listening for full response even at very low levels

•Volume control

•On/Off push button

•Green on/off light

•Headphone jack located on front of speaker

•Line in for CD and other devices

•Color coded connectors for easy hook-up

•Integrated, low distortion, stereo amplifier rated at 10 watts per channel (RMS at 1% THD)

•Exceptional low frequency output to 75 Hz provides wide spatial imaging

•Acoustically tuned bass reflex enclosure

•Low distortion, long throw, 3” full range drivers

•Power in one box – master/slave configuration

•External power supply

•Same color scheme as all Compaq products

DA-10407 World Wide — Version 3 — June 14, 2001 1
