WALL |
|
|
SHELL II 201-IW
D I R E C T- I N D I R E C T
•Semi – indirect light distribution.
•T5 and T8 lamping options.
•Die formed steel perforated housings.
•Modular housing lengths – 4’and 8’ for individual or continuous runs.
•Precision die cast end caps.
•Adjustable mounting block for accurate leveling.
S | |
[63mm] |
T8 = 1 Lamp
T5 = 1 or 2 Lamp
Construction
Housing is
End Caps
Standard end caps are precision
Reflectors
Reflector is
Electrical
Luminaires are prewired with quick wire connectors and use UL list Class P, T5HO or T8 electronic ballasts. Power factor of 97% with less than 10% THD. Fixtures and electrical components certified to UL and CUL standards.
Finish
Luminaire housings are standard white using electrostatically applied acrylic powder coat paint.
Mounting
Fixture mounts directly to existing structure over a 2” x 4” standard electrical box mounted horizontally in the wall.
S= Slim Line Ballast only.
ORDERING INFORMATION:
Sample number:
Series
201IW=Shell II Wall Mount
Optics Up
S=Specular
Optics Down
P=Perforated
Number of Lamps (not included) 1=1 Lamp 2=2 Lamps (T5 only)
Lamp Type |
|
|
|
T5HO=54W HO (4’ Unit) | T8=32W (4’ Unit) (1 Lamp only) | ||
Number of Circuits 1 |
|
| |
1=1 Circuit |
| 2=2 Circuits (Side by Side) | |
Wiring |
|
|
|
C=Standard Circuit | E=Emergency/Night Light | ||
D=Dimming |
| B=Battery Pack | |
Voltage 1 |
|
|
|
1=120V | 2=277V | 3=347V | U=Universal |
Run Length
Individual or continuous runs will be configured with 4’ and 8’ sections only (see sample catalog #)
1 Due to various constraints, some options may not be combined with others.
738 COOPER LIGHTING
S T A N D A R D L U M I N A I R E L E N G T H S *
48"[1219mm]*
96"[2438mm]*
*Dimensions do not include end caps.
END CAP
NOTES: For complete product data, refer to the
