Cooper Lighting 208 specifications Series

DESCRIPTION

208 Luminous Bowl features direct downlight component and a luminous bowl with an optional luminous cone.

SPECIFICATION FEATURES

Catalog #

Project

Comments

Prepared by

shaperlighting.com

Type

Date

Material	Lamp/Socket	Labels
Solid aluminum with a matte	One (1) 26W or 32W (GX24q-3)	U.L. and C.U.L. approved for
white acrylic bowl. Optional	4-pin triple CFL lamp or one (1)	indoor and damp location. See
matte acrylic cone.	100W A-19 lamp. CFL socket	options for damp location
	injection molded plastic. INC	finishing requirements.
Finish	socket fired ceramic rated for
Standard: Natural Aluminum	660W-250V. Lamps furnished by	Modifications
(NA) [Sustainable Design].	others.	Shaper's skilled craftspeople
Premium: Matte White (MW),		with their depth of experience
Lacquered Satin Aluminum	Installation	offer the designer the flexibility
(SAL), Satin Copper (SCP) or	Supplied with a universal	to modify standard surface
Custom Color (CC).	circular strap for a standard 4"	luminaires for project specific
	J-box or plaster ring.	solutions. Contact the factory
Optics		regarding scale options, unique
Refer to	Options	finishes, mounting, additional
www.shaperlighting.com for	Cone Diffuser (CD), Remote	materials/colors, or decorative
complete photometrics.	Emergency Battery - Supplied by	detailing.
	others (REM), Damp Location
Ballast	(DL): All Painted Finishes only,
Integral electronic HPF, multi-volt	CFL Dimming Ballast - Contact
120/277V (347V Canada),	the factory for ballast options
thermally protected with end-of-	(DM), MRI applications (INC only)
life circuitry to accommodate the	- Contact factory. Energy Star
specified lamp wattage.	Rating - consult factory.

ORDERING INFORMATION

Sample Number: 208-INC/1/100-120V-SCP

208 SERIES

S u r f a c e L u m i n a i r e

S t a r t e r C o l l e c t i o n

L u m i n o u s B o w l

STARTER

COLLECTION

Shaper’s exclusive Starter Collection fixtures are featured throughout the Shaper product line. The concept of offering highly styled, affordable fixtures was introduced over fourteen years ago and has become one of our fastest growing lines. The design premise, basic construction, clean lines and unadorned shapes are highly desirable in modern architectural environments.

SUSTAINABLE

DESIGN

Shaper has a long-standing history of offering environmentally-friendly fixtures. The copper and bronze alloys used in our exterior luminaires feature up to 98% re- cycled content, contribute less undesirable air emissions compared to painted alumi- num and are easy to recycle.

MAGNETIC

RESONANCE

IMAGING (MRI)

Series

208 =Bowl Surface

Luminaire

Notes:

1Available with CFL only.

2Consult the factory for available options.

3Supplied by others.

4Interior applications only.

Lamp

CFL/1 (26/32W- Triple)

INC/1/100

Voltage

120V

277V 1

347V 1

Finish

Standard

NA =Natural Aluminum

Premium

CC=Custom Color

MW=Matte White

SAL=Lacquered

Satin Aluminum

SCP=Satin Copper

Options

CONE =Cone Diffuser DL=Damp Location 4

DM =CFL Dimming

Ballast 2

REM=Remote

Emergency

Battery 3

Lighting fixtures for MRI facilities are specialized and unique, requiring non- ferrous construction. Fluorescent fixtures cannot be used due to the ferrous parts in ballasts and lampholders. Modified incan- descent fixtures meet the requirements.

ENERGY

STAR

Shaper now offers a wide variety of fixtures that can be provided with an Energy Star Rating.

Refer to the Icon Legend

Link on shaperlighting.com.

Specifications and dimensions subject to change without notice.

Consult your representative for additional options and finishes.
