COOPER LIGHTING - METALUX®

STRIPS AND INDUSTRIALS ACCESSORIES (ORDER SEPARATELY)

A C C E S S O R Y

D E S I G N AT I O N

D E S C R I P T I O N

Gripper Hanger

GRP-SS-U

For mounting on T-bar grid. Use two per fixture.



(Use with SS, IA/IC)

Can also be stem mounted or bolted to surface





using 11/16" hole provided. Fixture spacing 1-





1/2".



GRP-STN-U





(Use with STN, STM, IA/IC-HO)



ACCESSORIES

Tong Hanger



ATG-4-U

Heavy Gauge Channel Tong Hanger.







(Use with IA/IC-HO,STN, STM, DI,

Use two per fixture. Fixture spacing 1 1/2”.







DIM, DIVM, EI, EIM, EIVM)









ATG-5-U









(Use with STW)













Spacer





A-1-B/Spacer-U

Spaces fixture 1 1/2" to 2 1/2" from ceiling







(Use with all Strips and Industrials)











Suspension Sets











Stem Sets

SCF-XX-B

Fixed Stem Set







SCS-XX-B

Swivel Stem Set







(Deep canopy, 3/8" stem, 5/8"









outside diameter)









XX= Length 6, 8, 12, 24, 36, 48, 60, 72



SCF

SCS

SCA

SCA-48-B

Adjustable Stem Set (1/4" IPS Stem, 1/2" O.D.)











Used with all surface fixtures as stem sets. SCS stems have 45° swivel, one direction. One set







consists of one stem assembly. Minimum of two sets required per fixture. NOTE: Coupler, 3/8" IPS







Pipe Coupler to join lengths. Coupler is standard baked white enamel or special order of black.





Cable Sets

CCA-XX-PFC-U

CCA=Adjustable Cable (XX=48" or 120")







CCA-XX-PFS-U

CCF=Fixed Cable (XX=12", 15", 18", 21", 24" or

27")









CCA CCA CCA

PFC PFS NPF

CCA-XX-NPF-U

PFC=Power Feed, coil power cord

CCF-XX-PFC

PFS=Power Feed, straight power cord

CCF-XX-PFS

NPF=Non Power Feed

CCF-XX-NPF



Chain Hanger

AYC-Chain/Set-U

Sturdy wire hook and 36" chain set.



(Use with all strips and industrials

Use two per fixture. One set of two provided



except SN and STW)





Eye-Chain/ Set-B

Eye bolt and 36" chain.



(SN only)

Use two per fixture. One set of two provided



VT2-Chain/ Set-U

Eye bolt and 36" chain.



(VT2 only)



Channel Connector

CLC-B

Special rigid channel connector designed to give





extra support to continuous channel installation





(Use with SS, IA/IC). Provision for hanging





device. (LA City Approved)

DI Long Connector

DI2 Long Connector

Extra support heavy duty channel connector.



(Use with STN, STM, DI, DIM, DIVM,





EI, EIM, EIVM, IA/IC-HO)



Items listed are the major accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional





options and accessories are available.

COOPER LIGHTING

471

Consult Pre-Sales Technical Support for additional information.
