SHAPER

EXTERIOR

694-WP SERIES

694-WP Classic Quarter Sphere features bronze construction and is available in two sizes.

6"

6"

8"



8"



12"



6"

16"



8"

12" STANDARD



16" STANDARD





6"



8"







12"





16"





Sample Number: 694-WP-16-CFL/2-277V-GM







Series

Size

Lamp

Voltage

Finish5, 6

Options

694-WP=Classic

12"

CFL/1 (26/32W-Triple)1

120V

NBZ (standard),

C

Quarter Sphere

16"

CFL/2 (26/32W-Triple)2

277V3

BK, BM, CC, DP,

QR7





INC/1/751

347V4

GM, GRM, GY,

TGL7





INC/2/752



SCL, SM, SNL,







MH/1/502



VG, WH



Notes:



MH/1/702

















1. Available in 12". 2. Available in 16".

3. CFL and MH only. 4. Available with CFL only.





5.Premium TGIC polyester powder coat paint, 2.5 mil nominal thickness for superior protection against fade and wear.

6.Bronze will weather to a dark bronze patina. 7. MH only.

MATERIAL

Solid bronze with a 1/8" white acrylic diffuser for CFL/Incandescent and clear tempered refractive glass for MH.

BALLAST

Integral electronic HPF, multi-volt 120/277V (347V Canada), thermally protected with end-of-life circuitry to accommodate the specified lamp wattage. Metal halide ballast are HPF core & coil type, multi-volt 120/277V for the specified lamp wattage. 347V ballast for metal halide - Contact factory.

FINISH AND OPTIONS See page 1020 for finish details and options.

INSTALLATION Supplied with a mounting back for a standard 4" J-box or stucco ring. Optional rear (through wall) feed conduit mounting.

LAMP/SOCKET

12": One (1) 26W or 32W (GX24q-3) triple CFL lamp, or one (1) 75W

A-19 lamp.

16": Two (2) 26W or

32W (GX24q-3) triple CFL lamps, one (1) 50W or 70W ED-17 metal halide lamp or two (2) 75W A-19 lamps. CFL socket injection molded plastic. MH socket ceramic pulse-rated, 4KV. INC socket fired ceramic rated for 660W/250V. Lamps furnished by others.

WALL

694-WP-RB SERIES

694-WP-RB Classic Quarter Sphere with Round Back Panel features bronze construction.

7"

14" ø

14" ø

2"

7"

Sample Number: 694-WP-RB-INC/1/60-120V-GM





Series

Lamp

Voltage

Finish3, 4

Options

694-WP-RB =

CFL/1 (26/32/42W-Triple)

120V

NBZ (standard),

C

Classic Quarter

INC/1/60

277V1

BK, BM, CC, DP,

QR5

Sphere w/ Round

MH/1/50

347V2

GM, GRM, GY,



Back Panel

MH/1/70



SM, VG, WH



MATERIAL

Solid bronze with a white acrylic diffuser for CFL and Incandescent

and clear tempered refractive glass for MH.

BALLAST

Integral electronic HPF, multi-volt 120/277V (347V Canada), thermally protected with end-of-life circuitry to accommodate specified lamp wattage. Metal halide ballasts are electronic HPF, multi-volt 120/277V for the specified lamp wattage. 347V ballast for metal halide - Contact factory.

INSTALLATION Supplied with a mounting

LAMP/SOCKET

One (1) 26W, 32W (GX24q-3) or 42W

(GX24q-4) triple CFL lamp, one (1) 50W, 70W or

100W ED-17 metal halide lamp or one (1) 60W A-19 lamp. CFL socket injection molded plastic. Metal halide socket

is ceramic pulse-rated, 4KV. INC socket fired ceramic rated for

660W-250V. Lamps furnished by others.

FINISH AND OPTIONS See page 1020 for finish details and options.

Notes:

MH/1/100

back for a standard 4" J-box or stucco ring.

1 CFL and MH only.

2 Available with CFL only.

3 Premium TGIC polyester powder coat paint, 2.5 mil nominal thickness for superior protection against fade and wear. 4 Bronze will weather to a dark bronze patina.

5 MH only.

Optional rear (through wall) feed conduit mounting.

695-WP SERIES

695-WP Half Pyramid with direct illumination.

24"

18"

10"13-1/2"





8"









18"







13-1/2"











18" STANDARD















18-1/4"



Sample Number: 695-WP-24-CFL/2-277V-GM







Series

Size

Lamp

Voltage

Finish5

Options

695-WP =

18"

CFL/1 (26/32W-Triple)

120V

NBZ (standard),

C

Half Pyramid

24"

CFL/2 (26/32W-Triple)

277V3

BK, BM, CC, DP,

PH





INC/1/751

347V4

GM, GRM, GY,

QR6





INC/2/752



SCL, SM, SNL,

TGL6





MH/1/502



WH







MH/1/702







MH/1/1002

Notes:

1.Available in 18". 2. Available in 24". 3. CFL and MH only. 4. Available with CFL only.

5.Bronze will weather to a dark bronze patina. 6. MH only.

MATERIAL

Solid bronze construction with a clear textured refractive glass lense for MH or white acrylic lense for incandescent and CFL lamps. Optional tempered clear lense for full cut-off applications.

BALLAST

Integral electronic CFL HPF multi-volt 120V/277V (347V Canada), thermally protected with end-of-life circuitry to accommodate specified lamp wattage. Integral metal halide ballast is magnetic HPF, coil and core multi-volt 120/277V for the specified lamp wattage. 347V ballast for metal halide - Contact factory.

FINISH AND OPTIONS

See page 1020 for finish details and options.

INSTALLATION Supplied with a universal mounting back for a standard 4" J-box or plaster ring. Optional rear (through wall) feed conduit mounting.

LAMP/SOCKET

18": One (1) 26W or 32W (GX24q-3) 4-pin triple tube CFL lamp or one (1) 75W A-19 lamp.

24": Two (2) 26W or 32W (GX24q-3) 4-pin triple tube CFL lamps or one (1) 50W, 70W or 100W ED-17 metal halide lamp or two (2)

75W A-19 lamps. CFL socket injection molded plastic. INC socket fired ceramic rated for 660W- 250V. Metal halide socket is ceramic pulse-rated, 4KV. Lamps furnished by others.

COOPER LIGHTING 997

Page 1
Image 1
