DESCRIPTION

652 Direct Cylinder with Luminous Edge and 653 Direct/Indirect Cylinder with a Luminous Edges and a double arm wall bracket.

SPECIFICATION FEATURES

Catalog #

Project

Comments

Prepared by

shaperlighting.com

Type

Date

Material

Lamp/Socket

Painted Finishes only. Energy

Solid aluminum. 1/4" Matte

652: One (1) 26W or 32W

Star Rating - Consult factory. MRI

acrylic edge(s).

(GX24q-3) 4-pin triple CFL lamps,

Applications (INC only) - Contact



one (1) 50WPAR20H or

Factory.

Finish

75WPAR30 lamp or one (1) 75W



Standard: Unlacquered Natural

A-19 lamp. 653:Two (2) 26W or

Labels

Aluminum (NA).[Sustainable

32W (GX24q-3) 4-pin triple CFL

U.L. and C.U.L approved for

Design] Premium: Matte White

lamps, two 50WPAR20H or

indoor and damp location. See

(MW), Lacquered Satin

75WPAR30 lamps or two (2) 75W

options for damp location

Aluminum (SAL), Satin Copper

A-19 lamps. CFL socket injection

finishing requirements.

(SCP), Polished Copper (PCP) or

molded plastic. INC socket fired



Custom Color (CC).

ceramic rated for 660W-250V.

Modifications



Lamps furnished by others.

Shaper's skilled craftspeople

Optics



with their depth of experience

Refer to

Installation

offer the designer the flexibility

www.shaperlighting.com for

Supplied with a universal

to modify standard wall

complete photometrics.

circular strap for a standard 4"

luminaires for project specific



J-box or plaster ring.

solutions. Contact the factory

Ballast



regarding scale options, unique

Integral electronic HPF, multi-volt

Options

finishes, mounting, additional

120/277V (347V Canada),

Dimming Ballast - Contact

materials/colors, or decorative

thermally protected with end-of-

factory, Remote Emergency

detailing.

life circuitry to accommodate the

Battery - Supplied by others



specified lamp wattage.

(REM), Damp Location (DL): All



ORDERING INFORMATION

Sample Number: 652-CFL/1-277V-PCP

652SERIES

653SERIES

I n t e r i o r Wa l l L u m i n a i r e S t a r t e r C o l l e c t i o n A r m M o u n t C y l i n d e r

STARTER

COLLECTION

Shaper’s exclusive Starter Collection fixtures are featured throughout the Shaper product line. The concept of offering highly styled, affordable fixtures was introduced over fourteen years ago and has become one of our fastest growing lines. The design premise, basic construction, clean lines and unadorned shapes are highly desirable in modern architectural environments.

SUSTAINABLE

DESIGN

Series

652 =Direct Cylinder

w/ Luminous Edge

653 =Direct/Indirect Cylinder

w/ Luminous Edge

Notes:

1Available with 652 Series

2Available with 653 Series

3Available with CFL only.

4Supplied by others.

Lamp

CFL/1 (26/32W-Triple) 1 CFL/2 (26/32W-Triple) 2 INC/1/75 1

INC/2/75 2

PARH/1 1

PARH/2 2

Voltage

120V

277V 3

347V 3

Finish

Standard

NA =Natural Aluminum

Premium

CC=Custom Color

MW=Matte White

PCP =Polished Copper

SAL =Lacquered

Satin Aluminum

SCP =Satin Copper

Options

DL =Damp Location

REM =Remote

Emergency

Battery 4

Shaper has a long-standing history of offering environmentally-friendly fixtures. The copper and bronze alloys used in our exterior luminaires feature up to 98% re- cycled content, contribute less undesirable air emissions compared to painted alumi- num and are easy to recycle.

MAGNETIC

RESONANCE

IMAGING (MRI)

Lighting fixtures for MRI facilities are specialized and unique, requiring non- ferrous construction. Fluorescent fixtures cannot be used due to the ferrous parts in ballasts and lampholders. Modified incan- descent fixtures meet the requirements.

ENERGY

STAR

Shaper now offers a wide variety of fixtures that can be provided with an Energy Star Rating.

Refer to the Icon Legend

Link on shaperlighting.com.

Specifications and dimensions subject to change without notice.

Consult your representative for additional options and finishes.

ADS042680 2008-09-16 13:32:41

Page 1
