12-1/8" - 12-3/8" [308mm - 314mm] 11-1/4" [286mm]

HOUSING WIDTH

9" [229mm]

FIXTURE OPENING

TIE WIRE

(NOT BY NEORAY) (4 TWISTS MINIMUM)

9"

[229mm]

OVERALL HEIGHT

ORDERING INFORMATION:

Sample number: 79OS-1T8-4-1EB-SI

Series 79OS

Number of Lamps (not included) 1=1 Lamp

Lamp Type

T8T5

Run Length

Overall Nominal Run Length__ft. (Any combination of 8’, 6’, 4’ and 3’ sections)

NEO-RAY

PERIMETER



79-OS

Construction

20-gauge steel housing.

Electrical

120, 277, 347 or Universal Voltage electronic ballast. Fixtures and electrical components certified to UL and CUL standards.

Finish

Durable, low gloss, white, powder coated acrylic finish.

Mounting

Recessed.

Voltage 1







1=120V

2=277V

3=347V

U=Universal

Ballast







EB=Electronic Ballast (Standard)

DB=Dimming Ballast

Switching

SI=Single Switching

Emergency

EM=Emergency Pack (Consult Factory)

Fusing

GLRGMF

1 Due to various constraints, some options may not be combined with others.

I N D I R E C T

Direct wall wash light distribution.

T5 and T8 lamping.

Softly graduated wall illumination without lamp socket shadows.

Factory prepared inside and outside mitered corners, create a refined finished detail at the ceiling line.

Lamps shielded from all viewing angles.

Die formed steel housing.

Runs are field adjustable.

Illuminated wall continues above the ceiling line to create floating ceiling effect.

90 degree mitered corners.

Contractor friendly installation.

R U N S A N D P A T T E R N S





11-3/8"



12-1/8"

PATTERNS ARE PROVIDED WITH

90˚ Inside Corner

CORNER SECTIONS.



FIELD DIMENSIONS ARE REQUIRED.



FILLER SECTIONS ARE CUT TO LENGTH IN THE FIELD.



90˚ Inside Corner

2"

8" Filler Section

NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.

COOPER LIGHTING 767

Page 1
Image 1
