| PORTFOLIO™ | ||
|
|
|
|
|
|
| HOUSING |
Dimensions | Length | Width | Height Cutout | 4" Low Voltage Directional |
|
| 4" |
Standard Housing | 17" | PAR16/20/30 |
|
|
| ||
Chicago Plenum | 17" |
|
|
| |||
|
|
|
| ||||
|
|
|
| Open directional for vertical |
|
|
|
|
|
|
| downlighting in sloped ceilings or |
|
|
|
|
|
|
| for accent/display lighting. |
|
|
|
|
|
|
| Lockable 358° rotation and 35° tilt |
|
|
|
|
|
|
| with center beam optics provides |
|
|
|
|
|
|
| full output with no flashback. |
|
| H7443T |
|
|
|
|
|
|
| |
HOUSING |
|
|
| OPTIONS | ACCESSORIES |
|
|
H7443T=Directional Par Lamp |
|
| DR*=DeRated Wattage Label, | H277=Step Down Transformer, 300VA Max | |||
H7443TCP=Directional Par Lamp, Chicago Plenum | Specify Wattage | HB26=C Channel Bar Hanger, 26” Long, Pair | |||||
|
|
|
|
| HB50=C Channel Bar Hanger, 50” Long, Pair | ||
|
|
|
|
| RMB22=Wood Joist Bar Hanger, 22” Long, Pair | ||
|
|
|
|
| FK5=Field Installed Fuse Kit, 5 Amp |
| |
|
|
|
|
| L200 Series=Optical Lenses for PAR Lamps, | ||
|
|
|
|
| use with LC30 Lens Clip |
|
|
|
|
|
|
| LC30=Lens Holder for PAR30 Lamps |
| |
|
|
|
|
| and L200 Series Lens |
|
|
|
|
|
|
|
|
| TRIM |
|
| TRIM |
| FINISH | OPTIONS |
| Angle Cut |
|
| 9471=Self Flanged | LI=Low Iridescent Clear | WF=White | PAR16/PAR20/PAR30 75W Max | ||
|
| 9473=Metal Trim Ring, White | H=Haze | Painted Flange | |||
|
|
|
| ||||
|
|
|
| WMH=Warm Haze | (Self Flanged |
|
|
|
|
| G=Gold | only) |
|
| |
|
|
| WH=Wheat |
|
|
| |
|
|
| B=Black |
|
|
|
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
BB=Black Baffle (9473 only)
WB=White Baffle (9473 only)
Ordering Example | Housing | Trim | Accessories |
|
|
| |
Housing, Trim, Accessories and Lamps ordered as separate line items. | H7443T | 9471LIWF | HB26 |
|
|
|
|
