HALO®

TRACK LIGHTING Wall

L 1 7 5 3 Q u a r t z Wa l l Wa s h e r

Notes: Provides uniform illumination with sharp cutoff at top and bottom

Finish: White (P), Black (MB)

Lamp: 250W T4 Tungsten Halogen

M BFrosted Mini-Candelabra Base

Accessories: L978 Barn Doors

	BARN DOORS	250W
		TUNGSTEN
	AVAILABLE
P		HALOGEN

			L 9 7 7 B a r n D o o r S h u t t e r s
		L 9 7 8	For use with L1752 Quartz lamp wall wash lampholder.
Lampholder/Track Compatibility			L 9 7 8 B a r n D o o r S h u t t e r s
			For use with L1753 Quartz lamp wall wash lampholder.
L1751
			Finish: Black (MB)
	Halo Single and 2-Circuit	Lazer Track
L1752	L650, L651, L652, L653	LZR102, LZR104,
	L641, L642, L643	LZR106, LZR108
	L611, L612, L613
	L1631, L1632

3 5/8"	3"
	(76mm)
(92mm)
	8"
	(203mm)

Max. Extension: 6 1/2” (165mm)

COMPACT FLUORESCENT WALL WASHERS

P a r a Tr a c C o m p a c t F l u o r e s c e n t Wa l l Wa s h e r

L 3 2 4 0 E ( 2 ) 4 0 W B X L a m p

L 3 2 5 0 E ( 2 ) 5 0 W B X L a m p

L 3 2 5 5 E ( 2 ) 5 5 W B X L a m p

			M B	Finish:			White (P), Black (MB)
				Lamp:			Two 40W, 50W , 55W F40BX Compact Fluorescent
Shown with
Optional Louver		P
	L a m p h o l d e r		F i n i s h e s
Tr a c k S y s t e m						Vo l t a g e			L o u v e r
L=Halo Power-Trac	3240E=40W		P=White	Blank=120V				LVR3240P=White
LA=Halo Linear	3250E=50W		MB=Black	277=277V (for Halo Architectural				LVR3240SC=Specular Clear
Architectural	3255E=55W				Track Only)			LVR3240SC=Specular Clear

24 15/16" (635mm)

Max.

6"Extension:

(152mm) 8 1/16” (205mm)

Shown with

Optional Louver

L 3 2 3 2 E P a r a Tr a c Tr i p l e Tw i n

C o m p a c t F l u o r e s c e n t Wa l l Wa s h e r

N o t e s : Not for use with Four Circuit Trac

Finish: White (P), Black (MB)

PLamp: Two 32W F32TTT Compact Fluorescent

M B

16 15/16" (430mm)

Max.

Extension:

8 1/16”

6"(205mm) (152mm)

Tr a c k S y s t e m L a m p h o l d e r F i n i s h e s Vo l t a g e L o u v e r

3232E

	L=Halo Power-Trac		3232E=32W		P=White		Blank=120V				LVR3232P=White
	LA=Halo Linear				MB=Black		277=277V (for Halo Architectural				LVR3232MB=Black
	Architectural						Track Only0				LVR3232SC=Specular Clear
Lampholder/Track Compatibility								Lampholder/Track Compatibility
	L3240E	Halo Single and 2-Circuit		Halo 4-Circuit		Lazer Track		LA3240E	Halo “LA” Architectural
	L3250E	L650, L651, L652, L653		L963 Converter required for		LZR102, LZR104,		LA3250E		LA631, LA632, LA633
	L3255E	L641, L642, L643		use with Halo 4-Circuit:		LZR106, LZR108		LA3255E
	L3232E	L611, L612, L613		L621, L622, L623				LA3232E
		L1631, L1632

308COOPER LIGHTING
