A R E A |
|
| |
MFT LANDAU |
| ||
| MH/HPS/SMH | |||
L A R G E A R E A L U M I N A I R E |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
28 1/8" [714mm]
9 7/8"
[251mm]
21 13/16" [554mm]
STREETWORKS™
H O U S I N G
Formed aluminum housing. ANSI wattage/source label.
R E F L E C T O R
Anodized, specular aluminum reflector is
G A S K E T I N G
High temperature door gasket.
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : M F T 9 1 M W W F T 4
PRODUCT | LAMP | LAMP TYPE 1 | BALLAST | VOLTAGE 1 | DISTRIBUTION | OPTIONS + |
FAMILY | WATTAGE | S=High Pressure Sodium | TYPE 1 | 2=120V | FT=Forward Throw | ACCESSORIES |
MFT=Landau | 40=400W | R=SMH | W=CWA | 0=208V | 3D=Type III MCO | (See Below) |
| 91=1000W | M=Metal Halide |
| 4=240V |
|
|
|
|
|
| 7=277V |
|
|
|
|
|
| 8=480V |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
D O O R
Extruded aluminum hinged door with
B A L L A S T
Removable ballast assembly with quick disconnect.
F I N I S H
Standard polyester powder coat finish in bronze. For more color options see optional colors or consult your Streetworks represenatitive for more information.
O P T I O N S + A C C E S S O R I E S [ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
OPTIONS (add as suffix) | ACCESSORIES (order separately) |
1=Single Fused, Internally Mounted (120 or 277V) | OA1016=Photoelectric Control, |
2=Double Fused, Internally Mounted (208, 240, or 480V) | OA1027=Photoelectric Control, |
4=Photocontrol Receptacle | OA1066=Mast Arm Adapter for Existing 2 3/8" O.D. Horizontal Arm |
WH=White | OA1090=Adjustable Slipfitter for 2 3/8" O.D. Vertical Tenon |
BK=Black | OA1149=Polycarbonate Vandal Shield, Field Installed |
AP=Grey | OA1156=6" Rectangular Arm for Square Pole, .20 EPA |
DP=Dark Platinum | OA1157=12" Rectangular Arm for Square Pole, .50 EPA |
GM=Graphite Metallic | OA1158=18" Rectangular Arm for Square Pole, .70 EPA |
AIR=Arm Included for Round Pole | |
AIS=Arm Included for Round Pole | |
L=Lamp Included | OA1161=Direct Crossarm Mounting Set |
HS=House Side Shield | OA1167=6" Rectangular Arm for Round Pole, .20 EPA |
| OA1168=12" Rectangular Arm for Round Pole, .50 EPA |
| OA1169=18" Rectangular Arm for Round Pole, .70 EPA |
| OA1201=Photoelectric Control, 347 Volt NEMA Type |
O P T I O N A L C O L O R S [ S t a n d a r d c o l o r i s b r o n z e , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
WH | BK | AP | DP | GM |
White | Black | Grey | Dark Platinum | Graphite Metallic |
S H I P P I N G D ATA |
|
Approximate Net Weight: |
|
62 lbs. (28.12 kgs.) | NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. |
108 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s | C o o p e r L i g h t i n g |
