COOPER LIGHTING - METALUX®

DESCRIPTION

Ecofit conversion kits are an economical means of increasing fixture efficiency and energy savings. Ecofit conversion kits are ideal for applications where fixture removal is cost-prohibitive.

Ecofit conversion kits are designed for applications with conventional

3- or 4-lamp recessed 2' x 4' fixtures. Retrofitting 3-and 4-lamp troffers to

2-lamps with high performance retrofit conversion kits can reap up to 50% energy savings.

Catalog #

Project

Comments

Prepared by

TypeDate

SPECIFICATION FEATURES

A ... Construction

Socket tracks are die formed

20 gauge cold rolled steel. Toolless ballast access for easy wiring access and installation.

B ... Electrical

Optional electronic ballasts are Class "P" and are positively secured by mounting bolts. Twistlock lampholders.

(1)UL/CUL listed. Suitable for damp locations.

C ... Optical Modules

Die formed reflectors are faceted for 2 lamp configuration with two optical distributions: medium and wide. Medium beam optical modules utilize 95% specular Miro 4 substrate while the wide distribution utilizes a high performance 91% reflective polyester powder coated finish.

D ... Mounting

Retrofit installation in standard

2' x 2' and 2' x 4' recessed troffers. Hardware included.

ECOFIT

TROFFERS

2' x 2', 2' x 4'

2 OR 3 LAMPS

Energy Efficient Conversion Kit

A B C D

1-7/8" [48mm]

Length=45-1/2"

[1143mm]

19-13/16" [505mm]

LAMP CONFIGURATIONS INSTALLATION

1-7/8"

[48mm]

9-3/4" [248mm]

19-3/16" [505mm]

All components reflectors, reflector end caps, socket brackets, sockets, screws, and wire nuts) are included in each kit for installation and require only a few basic tools for assembly.

LAMPS CONTAIN MERCURY. DISPOSE ACCORDING

TO LOCAL, STATE OR FEDERAL LAWS

Safe and convenient means of

disconnecting power

Specifications and Dimensions subject to change without notice.	ADF071341
Consult your representative for additional options and finishes.	08/02/2008 3:26:09 PM
