PM50
C
L
C
L
BUSWAY SURFACE
370º Locking
Adjustability 270º Locking
Adjustability
5.59”
6.91”
3.57”
6.07”
7.64”
5.95”
PM614ob
60 Amp Busway Adapter
Catalog #
Type
Project
A machined aluminum track fixture for low voltage
AR111 lamps from 35 to 100 watts. For use with RSA
Profile Series 60 Amp Busway.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
AR111 12V
Open Back Machined Fixture
PM614ob
Ordering Example: PM614ob-50-AL
Open Back Machined Fixture Lamp Wattage Finish
❑ PM614ob - AR111 for 60 Amp Busway ❑ 35 35 Watt 12V AR111 ❑ WH White
❑ 50 50 Watt 12V AR111 ❑ BK Black
❑ 75 75 Watt 12V AR111 ❑ AL Natural Aluminum
❑ 100 100 Watt 12V AR111 ❑ PT Custom Finish
