PAR36 12V

Open Back Machined Fixture PM615ob

A machined aluminum track fixture for low voltage PAR36 lamps for 35 or 50 watts. For use with RSA Profile Series 60 Amp Busway.

Front loading lamp with bayonet action lens / accessory bezel. Optical accessories are captured in the bezel with a threaded retainer ring preventing accessory spill-out during relamping. Can accom- modate up to three optical accessories.

Catalog #

Type

Project

PM615ob

60 Amp Busway Adapter

Auto extending / retracting lamp holder. Lamps extend for easy access and automatically retract to optimum position. This is extremely helpful when dealing with varying accessory combinations or dif- fering manufacturer lamp dimensions.

Optical accessories include color filters, UV fil- ters, screens, spread lenses, louvers, hex louvers, snoots. Consult RSA for details.

Locking on both the horizontal and vertical planes. 370º vertical rotation possible due to over- center locking mechanism (60 amp busway only). 270º horizontal locking adjustment.

UL and CUL listed

Available in White, Black, Natural Aluminum or custom finishes.

BUSWAY SURFACE



6.07”

C



L

370º Locking

270º Locking

Adjustability

Adjustability 6.91”

5.95”



7.64”

C

3.57”

L



5.59”

Open Back Machined Fixture

Lamp Wattage

Finish













PM615ob - PAR36 for 60 Amp Busway

35

35 Watt 12V PAR36

WH

White













50

50 Watt 12V PAR36

BK

Black

















AL

Natural Aluminum

















PT

Custom Finish

Ordering Example: PM615ob-50-AL











RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311

















®

Toll Free: 800-356-3030818-349-3030 • Fax: 818-349-3031









www.rsalighting.com

©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice

www.cooperlighting.com

PM58

Page 1
Image 1
