DESCRIPTION
3.5” Round Downlight MR16 trim with smooth splay regress. For use with Armstrong® TechZone™ Ceiling products.
Trim face has Armstrong White finish with flat black internal finish
SPECIFICATION / FEATURES
Catalog #
Project
Comments
Prepared by
Type
Date
A....Housing
All aluminum construction with 18” of flexible conduit attached to a cylindrical transformer/wiring enclosure. Mounting hardware suited for TechZone™ ceilings exclusively.
B....Trim:
3.5” o.d. round trim with smooth splay regress. Finished in Armstrong® white.
C....System Protection:
Thermal protection inside housing. Vent holes in housing provide cooler operation. All aluminum construction provides overall reduced temperatures.
D....Electrical
Electronic transformer housed in a separate metal enclosure. Enclosure includes a separated wiring compartment and entry for primary leads.
E....Lamp
12V MR16 37 watts max. (not included)
18.00” |
|
Flexible Conduit | 6.00” |
LYNX
Armstrong® TechZone™ Compatible
6.00”
Smooth | Acoustical Tee |
Splayed | |
Regress | Mounting Brackets |
2.00”
Integral Electronic Low Voltage Transformer with Thermal Protection and Wiring Compartment in Cylindrical Enclosure
TZ3003
3.5” Round
Downlight
Smooth Splay
Regress
FOR 12V MR16 37 watts max.
3.50”
2.30”
ORDERING INFORMATION
TZ3003
TZ3003
3.5” Round Trim with Smooth Splay Regress
Includes Housing with Integral Electronic Transformer and
12V MR16 37W max.
Specifications and Dimensions subject to change without notice. | rev. 072007 |
